This list of Intel processors by generation attempts to present all of Intel's processors from the 4-bit 4004 (1971) to the present high-end offerings. Concise technical data is given for each product.

Latest

edit

Xeon 6+

edit

Released at Computex 2026 on June 1, 2026. Codenamed Clearwater Forest it is designed for network infrastructure and data center servers featuring. It supports up to 1.5 TB of DDR5 RDIMMM 8000MT/s RAM and ECC memory.[1]

Accellerated Processor Server

edit

Underlined models support Intel Speed Select. All models are E-Core only.

Xeon 6900E+ Series (Codenamed "Clearwater Forest-AP")
Processor Family Model Cores Configuration Clock rate (GHz) Cache Max. Scalability Memory Support TDP Release date
Tiles Core Config Base Turbo Memory speed Memory channels
Xeon 6+ 6990E+ 288 (288) 12x Compute tile
3x Active base tile
2x I/O tile
12x EMIB tile 		12x 24 2.2 3.2 576 MB 2S DDR5-8000 RDIMM 12 450 W June 1, 2026
6980E+ 264 (264) 11x Compute tile
3x Active base tile
2x I/O tile
11x EMIB tile 		11x 24 2.1 528 MB 400 W
6970E+ 192 (192 8x Compute tile
3x Active base tile
2x I/O tile
8x EMIB tile 		8x 24 2.3 480 MB
6960E+ 144 (144) 6x Compute tile
3x Active base tile
2x I/O tile
6x EMIB tile 		6x 24 2.4 432 MB 330 W


Core Series 3

edit

Announced at CES 2026 on January 5, 2026. Codenamed Panther Lake, which only includes mobile processors and handheld gaming processors.

Mobile processors

edit
Premium
edit
High Power
edit

Underlined models support Intel vPRO.

Core Ultra 300H Series (codenamed "Panther Lake High Power")
Branding SKU Cores Clock rate (GHz) Arc Graphics NPU
(TOPS) 		Cache Power Released
Base Turbo
P E LP-E Total P E LP-E P E LP-E Branding Xe Cores
(VE:RT) 		Clock
(GHz) 		L0 L1 L2 L3 Base Turbo
Core Ultra X9 388H 4 8 4 16 2.1 1.6 5.1 3.8 3.7 Intel Arc B390 12 (96:12) 2.5 50 192 KB 2.2 MB 22 MB 18 MB 25 W 80 W January 5, 2026
378H 2 5 3.6 April 4, 2026
Core Ultra X7 368H January 5, 2026
358H 1.9 1.5 4.8 3.5 3.3
Core Ultra 9 386H 2.1 1.6 4.9 3.7 3.5 Intel Graphics 4 (32:4)
Core Ultra 7 366H 2 4.8 3.6 3.4
356H 1.9 1.5 4.7 3.5 3.3 2.45
Core Ultra 5 338H 2 14 3.4 Intel Arc B370 10 (80:10) 3.4 47 1.8 MB 18 MB
336H 4.6 3.2 Intel Graphics 4 (32:4) 2.3
Low Power
edit

Underlined models support Intel vPRO.

Core Ultra 300 Series (codenamed "Panther Lake")
Branding SKU Cores Clock rate (GHz) Arc Graphics NPU
(TOPS) 		Cache Power Released
Base Turbo
P LP-E Total P LP-E P LP-E Branding Xe Cores
(VE:RT) 		Clock
(GHz) 		L0 L1 L2 L3 Base Turbo
Core Ultra 7 365 4 4 8 2.4 1.8 4.8 3.6 Intel Graphics 4 (32:4) 2.5 49 192 KB 1.4 MB 14 MB 12 MB 25 W 55 W January 5, 2026
355 2.3 1.7 4.7 3.5 2.45
Core Ultra 5 335 2.2 1.6 4.6 3.4 3.4 47
332 2 6 1.6 1.9 4.4 3.3 2.3 46 96 KB 896 KB 9 MB
325 4 8 2.1 1.6 4.5 3.4 2.45 47 192 KB 1.4 MB 14 MB
322 2 6 2.5 1.9 4.4 3.3 2.3 46 96 KB 896 KB 9 MB
Value
edit
Low Power
edit

Italic models are in Intel SIPP (Stable IT Platform Program).

Core 300 Series (codenamed "Wildcat Lake")
Branding SKU Cores Clock rate (GHz) Arc Graphics NPU
(TOPS) 		Cache Power Released Price
(USD)
Base Turbo
P LP-E P LP-E P LP-E Xe Cores
(VE:RT) 		Clock
(GHz) 		L0 L1 L2 L3 Base Turbo
Core 7 360 2 4 6 1.5 1.4 4.8 3.6 2 (16:2) 2.6 17 96 KB 896 KB 9 MB 6 MB 15 W 35 W April 16, 2026 $426
350 $469
Core 5 330 4.6 3.4 2.5 16 $309
320 $340
315 4.4 3.3 2.3 15
Core 3 305 4.3 1 (8:1) $309
304 1 5 48 KB 640 KB 6.5 MB

Handheld Gaming

edit
Arc G3 Series (codenamed "Panther Lake")
Branding SKU Cores Clock rate (GHz) Arc Graphics NPU
(TOPS) 		Cache Power Released
Base Turbo
P E LP-E Total P E LP-E P E LP-E Branding Xe Cores
(VE:RT) 		Clock
(GHz) 		L0 L1 L2 L3 Base Turbo
Arc G3 EXTREME 2 8 4 14 1.9 1.5 4.7 3.4 3.1 Intel Arc B390 12 (96:12) 2.3 46 96 KB 1.25 MB 13 MB 6 MB 25 W 80 W May 28, 2026
G3 4.6 3.3 Intel Arc B370 10 (80:10) 2.2


Core Series 2 Plus

edit

Released on March 26, 2026 as Arrow Lake Refresh.

Desktop

edit

Socket LGA 1851

Core Ultra 200S Plus Series (Codenamed "Arrow Lake-S Refresh")
Branding SKU Cores Clock rate (GHz) Arc Graphics TOPS (Int8) Cache Power Released Price
(USD)
Base Turbo
P E Total P E P E Xe Cores
(VE:RT) 		Clock
(GHz) 		NPU
Total L0 L1 L2 L3 Base Turbo
Core Ultra 7 270K Plus 8 16 24 3.7 3.2 5.5 4.7 4 (64:4) 2.0 13 36 384 KB 3.5 MB 40 MB 36 MB 125 W 250 W March 26, 2026 $299
Core Ultra 5 250K Plus 6 12 18 4.2 3.3 5.3 4.6 1.9 30 288 KB 2.6 MB 30 MB 30 MB 159 W $199
250KF Plus N/a 22 $184

Mobile

edit
Premium
edit
Repurposed Desktop
edit
Core Ultra 200HX Plus Series (Codenamed "Arrow Lake-HX Refresh")
Branding SKU Cores Clock rate (GHz) Arc Graphics TOPS (Int8) Cache Power Released Price
(USD)
Base Turbo
P E Total P E P E Xe Cores
(VE:RT) 		Clock
(GHz) 		NPU
Total L2 L3 Base Turbo
Core Ultra 9 290HX Plus 8 16 24 2.7 1.8 5.5 4.7 4 (64:4) 2.0 13 36 40 MB 36 MB 55 W 160 W January 6, 2025
Core Ultra 7 270HX Plus 12 20 2.4 5.3 1.9

Core Series 2

edit

Released on October 24, 2024. The Core Series 2 succeeded Meteor Lake, seeing Intel move from monolithic silicon to a disaggregated MCM design. Meteor Lake was limited to a mobile release while Arrow Lake includes desktop processors and mobile processors. Arrow Lake and Lunar Lake both do not support Hyper-Therading.

Desktop

edit

Socket LGA 1851. Underlined models support Intel vPRO with the Q870 (enterprise) and W880 (entry-level workstation) chipsets, and ECC memory only on the W880 chipset.

Core Ultra 200S Series codenamed ("Arrow Lake-S")
Processor Family Model Cores
(threads) 		Clock rate (GHz) Arc Graphics TOPS (Int8) Cache TDP Released Price
(USD)
Base Turbo
P E Total P E P E Xe Cores
(VE:RT) 		Clock
(GHz) 		NPU
Total L0 L1 L2 L3 Base Turbo
Core Ultra 9 285K 8 16 24 3.7 3.2 5.7 4.6 4 (64:4) 2.0 13 36 2.6 MB 3 MB 40 MB 36 MB 125 W 250 W October 6, 2025 $589
285 2.5 1.9 5.4 65 W 182 W January 6, 2025 $549
285T 1.4 1.2 5.3 35 35 W 112 W
Core Ultra 7 265K 12 20 3.9 3.3 5.5 33 2.2 MB 2.7 MB 36 MB 30 MB 125 W 250 W October 24, 2025 $394
265KF N/a 25 $379
265 2.4 1.8 5.2 4 (64:4) 1.95 33 65 W 182 W January 6, 2025 $384
265F N/a 25 $369
265T 1.5 1.2 4 (64:4) 1.95 33 35 W 112 W $384
Core Ultra 5 245K 6 8 14 4.2 3.6 4 (64:4) 1.9 30 288 KB 2.6 MB 24 MB 24 MB 125 W 159 W October 24, 2025 $309
245KF N/a 22 $294
245 3.5 3.0 5.1 4.5 4 (64:4) 1.9 29 65 W 121 W January 6, 2025 $270
245T 2.2 1.7 35 W 114 W
235 3.4 2.9 5.0 4.4 3 (48:3) 2.0 27 65 W 121 W $247
235T 2.2 1.6 35 W 114 W
225 4 10 3.3 2.7 4.9 2 (32:2) 1.8 23 1.1 MB 1.5 MB 22 MB 20 MB 65 W 121 W $236
225F N/a 19 $221
Core Ultra 3 205[2][3] 4 8 3.8 3.2 2 (32:2) 1.8 13 896 KB 16 MB 15 MB 57 W 76 W August, 2025 $130-$150 (Europe Only)

Mobile

edit
Premium
edit

Underlined models support Intel vPRO.

Repurposed Desktop
edit
Core Ultra 200HX (Codenamed "Arrow Lake-HX")
Processor Family Model Cores Clock rate (GHz) Arc Graphics TOPS (Int8) Cache TDP Released Price
(USD)
Base Turbo
P E Total P E P E Xe Cores
(VE:RT) 		Clock
(GHz) 		NPU
Total L2 L3 Base Turbo
Core Ultra 9 285HX 8 16 24 2.8 2.1 5.5 4.6 4 (64:4) 2.0 13 36 40 MB 36 MB 55 W 160 W January 6, 2025 $612
275HX 2.7 5.4 1.9 $680
Core Ultra 7 265HX 12 20 2.6 2.3 5.3 33 36 MB 30 MB $450
255HX 2.4 1.8 5.2 4.5 1.85 $507
251HX 6 16 2.9 2.5 5.1 3 (48:3) 1.8 30 30 MB
Core 7 245HX 8 14 2.6 27 26 MB 24 MB
Core Ultra 5 245HX 3.1 1.9 $306
235HX 2.9 1.8 $349
High Power
edit
Core Ultra 200H Series (Conedamed "Arrow Lake-H")
Processor Family Model Cores Clock rate (GHz) Arc Graphics TOPS (Int8) Cache TDP Released Price
(USD)
Base Turbo
P E LP-E Total P E LP-E P E LP-E Xe Cores
(VE:RT) 		Clock
(GHz) 		NPU
Total L2 L3 Base Turbo
Core Ultra 9 285H 6 8 2 16 2.9 2.7 1.0 5.4 4.5 2.5 8 (128:8) 2.35 13 99 26 MB 24 MB 45 W 115 W January 6th, 2025 $651
Core Ultra 7 265H 2.2 1.7 0.7 5.3 2.3 97 28 W $471
255H 2.0 1.5 5.1 4.4 2.25 96 $514
Core Ultra 5 235H 4 4 2.4 1.8 5 94 20 MB 18 MB $354
225H 1.7 1.3 4.9 4.3 7 (112:7) 2.2 83 $385
Low Power
edit

Arrow Lake-U uses refreshed Meteor Lake silicon fabricated on the Intel 3 node.

Core Ultra 200U Series (Codenamed "Arrow Lake-U")
Processor Family Model Cores
(threads) 		Clock rate (GHz) Arc Graphics TOPS (Int8) Cache TDP Released Price
(USD)
Base Turbo
P E LP-E Total P E LP-E P E LP-E Xe Cores
(VE:RT) 		Clock
(GHz) 		NPU
Total L0 L1 L2 L3 Base Turbo
Core Ultra 7 265U 2 (4) 8 (8) 2 (2) 12 (14) 2.1 1.7 0.7 5.3 4.2 2.4 4 (64:4) 2.1 12 24 96 KB 1.3 MB 14 MB 12 MB 15 W 57 W Jan 6, 2025 $448
255U 2.0 5.2 $490
Core Ultra 5 235U 1.5 4.9 4.1 2.05 $332
225U 1.5 1.8 4.8 3.8 2.0 $363
Ultra Low Power
edit

These parts are based on the Lunar Lake architecture and have on-package LPDDR5X-8533 RAM. Underlined models support vPro Enterprise.

Lunar lake does not support Hyper-Threading.

Core Ultra 200V Series (Codenamed "Lunar Lake")
Processor Family Model Cores Clock rate (GHz) Arc Graphics TOPS (int8) Smart Cache Memory capacity TDP Released
Base Clock (GHz) Turbo Clock (GHz)
P LP-E Total P LP-E P LP-E Xe Cores
(VE:RT) 		Max. freq. (GHz) NPU Total Base Turbo
Core Ultra 9 288V 4 4 8 3.3 5.1 3.7 8 (64:8) 2.05 48 120 12 MB 32 GB 30 W 37 W September 3, 2024[4]
Core Ultra 7 268V 2.2 5.0 2.0 118
266V 16 GB
258V 4.8 1.95 47 115 32 GB
256V 16 GB
Core Ultra 5 238V 2.1 4.7 3.5 7 (56:7) 1.85 40 97 8 MB 32 GB
236V 16 GB
228V 4.5 32 GB
226V 16 GB
Value
edit
High Power
edit

These processors are Re-Refreshes of Raptor Lake-H and not an Arrow Lake variant.

Core 200H Series (Codenamed "Raptor Lake-H Re-Refresh")
Processor Family Model Cores
(threads) 		Clock rate (GHz) Graphics Smart Cache TDP Released Price (USD)
Base Turbo
P E Total P E P E EUs Clock
(GHz) 		Base Turbo
Core 9 270H 6 (12) 8 (8) 14 (20) 2.7 2.0 5.8 4.1 96 1.55 24 MB 45 W 115 W Q1 2025 $697
Core 7 250H 2.5 1.8 5.4 4.0 $502
240H 4 (4) 10 (16) 5.2 64
Core 5 220H 4 (8) 8 (8) 12 (16) 2.7 2.0 4.9 3.7 80 1.5 18 MB 95 W $342
210H 4 (4) 8 (12) 2.2 1.6 4.8 3.6 48 1.4 12 MB
Low Power
edit

These processors are Re-Refreshes of Raptor Lake-U with Hyper-Threading disabled.

Core 200U Series (Codenamed "Raptor Lake-U Re-Refresh")
Processor Family Model Cores
(threads) 		Clock rate (GHz) Graphics Smart Cache TDP Released Price (USD)
Base Turbo
P E Total P E P E EUs Clock
(GHz) 		Base Turbo
Core 7 250U 2 (2) 4 (4) 6 (6) 1.8 1.2 5.4 4.0 96 1.3 12 MB 15 W 55 W Q1 2025 $426
Core 5 220U 1.4 0.9 5.0 3.8 80 $309


Embedded

edit

These are Raptor Lake models released for socket LGA 1700.

Hybrid
edit

Models in the table below feature a Hybrid design

Core 201E Series (Codenamed "Bartlett Lake")
Processor Family Model Cores Clock rate (GHz) Graphics Smart Cache TDP Released Price (USD)
Base Turbo Max.
P E Total P E P E EUs Clock
(GHz) 		Base
Core 5 211E 6 (12) 4 (4) 10 (16) 2.7 2.0 4.9 3.7 4.9 24 1.55 20 MB 65 W Q1 2025 $221
211TE 1.7 1.3 4.8 3.4 4.8 45 W
221E 6 (12) 8 (8) 14 (20) 2.7 2.1 3.9 5.2 5.2 32 24 MB 65 W $223
221TE 1.8 1.3 5.0 3.6 5.0 45 W
Core 7 251E 8 (16) 16 (16) 24 (32) 2.1 1.6 5.6 4.4 5.6 1.66 36 MB 65 W $384
251TE 1.4 1.0 5.4 3.9 5.4 1.6 45 W
P-Core only
edit

Models in the table below only contain P-Cores.

Core 203E Series (Codenamed "Bartlett Lake")
Processor Family Model Cores
(threads) 		Clock rate (GHz) Graphics Smart Cache TDP Released Price (USD)
Base Turbo Max. EUs Clock
(GHz) 		Base
Core 3 201E 4 (8) 3.6 4.8 4.8 24 1.55 12 MB 60 W Q1 2025 $134
201TE 2.9 4.6 4.6 45 W
Core 5 213PE 8 (16) 2.7 5.2 5.2 1.65 24 MB 65 W Q1 2026 $221
213PTE 2.1 45 W
223PE 8 (16) 2.9 5.4 5.4 32 1.65 65 W $232
223PTE 2.3 45 W
223PQE 4.0 5.5 5.5 125 W $313
Core 7 253PE 10 (20) 2.5 5.3 5.5 1.65 33 MB 65 W $384
253PTE 1.8 5.3 5.4 45 W
253PQE 3.5 5.5 5.7 125 W $409
Core 9 273PE 12 (24) 2.3 5.4 5.7 36 MB 65 W $549
273PTE 1.4 5.4 5.5 45 W
273PQE 3.4 5.5 5.9 125 W $589

Core Series 1

edit

Core Ultra Series 1 was launched on December 14, 2023[5] under the codename Meteor Lake with mobile Raptor Lake-U Refresh parts launching as Core Series 1.

Mobile

edit

Meteor Lake is the first Intel mobile generation to use a chiplet architecture, which means that the processor is a multi-chip module.[5]

Premium
edit

In June 2023, Intel unveiled new branding for the Meteor Lake processors, changing from the "Core i3/i5/i7/i9" branding to a new system of two brands: Core and Core Ultra, where Core is for everyday and value-oriented processors while Core Ultra is reserved for premium processors. These are also separated into Core 3/5/7/9 and Core Ultra 3/5/7/9.[6]

High Power
edit

Underlined models support Intel vPRO Enterprise.

Core Ultra 100H Series (Codenamed "Meteor Lake-H")
Processor Family Model Cores
(threads) 		Clock rate (GHz) Arc Graphics TOPS (Int8) Smart Cache Power Released Price
(USD)
Base Turbo
P E LP-E Total P E LP-E P E LP-E Xe Cores
(VE:RT) 		Clock
(GHz) 		NPU
Total Base Turbo
Core Ultra 9 185H 6 (12) 8 (8) 2 (2) 16 (24) 2.3 1.8 1.0 5.1 3.8 2.5 8 (128) 2.35 11 35 24 MB 45 W 115 W December 14, 2023 $640
Core Ultra 7 165H 1.4 0.9 0.7 5.0 2.3 34 28 W $460
155H 4.8 2.25 33 $503
Core Ultra 5 135H 4 (8) 14 (18) 1.7 1.2 4.6 3.6 2.2 18 MB $342
125H 1.2 0.7 4.5 7 (112) $375
Low Power
edit

Underlined models support Intel vPRO Enterprise.

Core Ultra 105U Series (Codenamed "Meteor Lake-U15")
Processor Family Model Cores
(threads) 		Clock rate (GHz) Arc Graphics TOPS (Int8) Smart Cache Power Released Price
(USD)
Base Turbo
P E LP-E Total P E LP-E P E LP-E Xe Cores
(VE:RT) 		Clock
(GHz) 		NPU
Total Base Turbo
Core Ultra 7 165U 2 (4) 8 (8) 2 (2) 12 (14) 1.7 1.2 0.7 4.9 3.8 2.1 4 (64) 2.0 11 22 12 MB 15 W 57 W December 14, 2023 $448
155U 4.8 1.95 $460
Core Ultra 5 135U 1.7 1.1 4.4 3.6 1.9 $322
125U 1.3 0.8 4.3 1.85 21 $363
115U 4 (4) 8 (10) 1.5 1.0 4.2 3.5 3 (48) 1.8 10 MB unspecified
Ultra Low Power
edit

All models support Intel vPRO Enterprise.

Core Ultra 104U Series (Codenamed "Meteor Lake-U9")
Processor Family Model Cores
(threads) 		Clock rate (GHz) Arc Graphics TOPS (Int8) Smart Cache Power Released Price
(USD)
Base Turbo
P E LP-E Total P E LP-E P E LP-E Xe Cores
(VE:RT) 		Clock
(GHz) 		NPU
Total Base Turbo
Core Ultra 7 164U 2 (4) 8 (8) 2 (2) 12 (14) 1.1 0.7 0.4 4.8 3.8 2.1 4 (64) 1.8 11 21 12 MB 9 W 30 W December 14, 2023 $448
Core Ultra 5 134U 0.7 0.5 4.4 3.6 1.75 $332
Value
edit

To fill out the value segment, Intel had refreshed their Raptor Lake products and branded them as Core Series 1

Low Power
edit

These processors are Re-Refreshes of Raptor Lake-U.

Core 100U Series (Codenamed "Raptor Lake-U Refresh")
Processor Family Model Cores
(threads) 		Clock rate (GHz) Graphics Smart Cache Power Released Price (USD)
Base Turbo
P E Total P E P E EUs Clock
(GHz) 		Base Turbo
Core 7 150U 2 (4) 8 (8) 10 (12) 1.8 1.2 5.3 4.0 96 1.3 12 MB 15 W 55 W Q1 2024
Core 5 120U 1.4 0.9 5.0 3.8 80 1.25 $340
Core 3 100U 4 (4) 6 (8) 1.2 4.7 3.3 64 10 MB
E-Core only
edit

These processors are Alder Lake.

Nx5x Series (Codenamed "Twin Lake-N")
Processor Family Model Cores
(threads) 		Clock rate (GHz) Graphics Smart Cache Power Released
Base Turbo EUs Clock
(GHz) 		Down Base
Core 3 N355 8 (8) 1.8 3.9 32 1.35 6 MB 9 W 15 W January 6, 2025
N350 0.8 Unknown 7 W
Intel Processor N250 4 (4) 1.2 3.8 1.25 6 W
N150 0.8 3.6 24 1.0

IoT/Embedded

edit

These are processors based on Meteor Lake-PS die and are designed for use in Internet of Things devices and embedded systems.

Premium
edit
High Power
edit
Core Ultra 100HL Series (Codenamed "Meteor Lake-PS")
Processor Family Model Cores
(Threads) 		Clock rate (GHz) Arc Graphics Smart Cache Power Released Price
(USD)
Base Turbo
P E LP-E Total P E LP-E P E LP-E Xe Cores
(VE:RT) 		Clock
(GHz) 		Base Turbo
Core Ultra 7 165HL 6 (12) 8 (8) 2 (2) 16 (24) 1.4 0.9 0.7 5.0 3.8 2.5 8 (128:8) 2.3 24 MB 45 W 115 W Q2 2024 $459
155HL 4.8 2.25 $438
Core Ultra 5 135HL 4 (8) 14 (20) 1.7 1.2 4.6 3.6 2.2 18 MB $341
125HL 1.2 0.7 4.5 7 (112:7) $325
Low Power
edit
Core Ultra 100UL Series (Codenamed "Meteor Lake-PS")
Processor Family Model Cores
(Threads) 		Clock rate (GHz) Arc Graphics Smart Cache Power Released Price
(USD)
Base Turbo
P E LP-E Total P E LP-E P E LP-E Xe Cores
(VE:RT) 		Clock
(GHz) 		Base Turbo
Core Ultra 7 165UL 2 (4) 8 (8) 2 (2) 16 (24) 1.7 1.2 0.7 4.9 3.8 2.1 4 (64:4) 2.0 12 MB 15 W 57 W Q2 2024 $447
155UL 4.8 1.95 $426
Core Ultra 5 135UL 1.6 1.1 4.4 3.6 1.9 $331
125UL 1.3 0.8 4.3 1.85 $309
Core Ultra 3 105UL 4 (4) 8 (10) 1.5 1.0 4.2 3.5 3 (48:3) 1.8 10 MB $295

14th generation Core i

edit

Desktop

edit

An iterative refresh of Raptor Lake-S desktop processors, called the 14th generation of Intel Core, was launched on October 17, 2023.[7][8]

Socket LGA 1700

Underlined models feature UDIMM ECC memory support when paired with a motherboard based on the W680 chipset according to each respective Intel Ark product page.

Core i5/i7/i9 14000 Series (Codenamed "Raptor Lake-S Refresh")
Processor
branding 		Model Cores
(threads) 		Clock rate (GHz) GPU Smart
cache 		TDP Price
(USD)[a]
Base Turbo Boost Model Max. freq.
(GHz)
2.0 3.0 TVB
P E Total P E P E P P Base Turbo
Core i9 14900KS 8 (16) 16 (16) 24 (32) 3.2 2.4 5.9 4.5 6.2 6.2 UHD 770 1.65 36 MB 150 W 253 W $689
14900K 5.6 4.4 5.8 6 125 W $589
14900KF N/a - $564
14900 2.0 1.5 5.4 4.3 5.6 5.8 UHD 770 1.65 65 W 219 W $549
14900F N/a - $524
14900T 1.1 0.8 5.1 4.0 5.5 N/a UHD 770 1.65 35 W 106 W $549
Core i7 14790F 8 (8) 16 (24) 2.1 1.5 5.3 4.2 5.4 N/a N/a 65 W 219 W China only
14700K 12 (12) 20 (28) 3.4 2.5 5.5 4.3 5.6 UHD 770 1.6 33 MB 125 W 253 W $409
14700KF N/a $384
14700 2.1 1.5 5.3 4.2 5.4 UHD 770 1.6 65 W 219 W
14700F N/a $359
14700T 1.3 0.9 5.0 3.7 5.2 UHD 770 1.6 35 W 106 W $384
Core i5 14600K 6 (12) 8 (8) 14 (20) 3.5 2.6 5.3 4.0 N/a 1.55 24 MB 125 W 181 W $319
14600KF N/a $294
14600 2.7 2.0 5.2 3.9 UHD 770 1.55 65 W 154 W $255
14600T 1.8 1.3 5.1 3.6 35 W 92 W

These models are actually Alder Lake.

Intel Processor 300/Core i3/5 14000 Series (Codenamed "Raptor Lake-S Refresh")
Processor
branding 		Model Cores
(threads) 		Clock rate (GHz) GPU Smart
cache 		TDP Price
(USD)[a]
Base Turbo Boost Model Max. freq.
(GHz)
2.0
P E Total P E P E Base Turbo
Core i5 14500 6 (12) 8 (8) 14 (20) 2.6 1.9 5.0 3.7 UHD 770 1.55 24 MB 65 W 154 W $232
14500T 1.7 1.2 4.8 3.4 35 W 92 W
14490F 4 (4) 10 (16) 2.8 2.1 4.9 3.7 N/a 65 W 148 W China only
14400 2.5 1.8 4.7 3.5 UHD 730 1.55 20 MB $221
14400F N/a $196
14400T 1.5 1.1 4.5 3.2 UHD 730 1.55 35 W 82 W $221
Core i3 14100 4 (8) N/a 4 (8) 3.5 N/a 4.7 N/a 1.5 12 MB 60 W 110 W $134
14100F N/a 58 W $109
14100T 2.7 4.4 UHD 730 1.5 35 W 69 W $134
Intel

Processor

300 2 (4) 2 (4) 3.9 N/a UHD 710 1.45 6 MB 46 W N/a $82
300T 3.4 35 W

Mobile

edit

An iterative refresh of Raptor Lake-HX mobile processors, called the 14th generation of Intel Core, was launched on Jan 9, 2024 [9]

Core i5/i7/i9 14000HX (Codenamed "Raptor Lake-HX Refresh")
Processor
branding 		Model Cores
(threads) 		Clock rate (GHz) UHD Graphics Smart
cache 		TDP Price
(USD)[a]
Base clock (GHz) Turbo Boost (GHz)
P E Total P E P E EUs Boost clock
(GHz) 		Base (cTDP) Turbo
Core i9 14900HX 8 (16) 16 (16) 24 (32) 2.2 1.6 5.8 4.1 32 1.65 36 MB 55 W (45 W) 157 W $679
Core i7 14700HX 12 (12) 20 (28) 2.1 1.5 5.5 1.6 33 MB $495
14650HX 8 (8) 16 (24) 2.2 1.6 5.2 3.7 16 30 MB
Core i5 14500HX 6 (12) 14 (20) 2.6 1.9 4.9 3.5 32 1.55 24 MB $337
14450HX 4 (4) 10 (16) 2.4 1.8 4.8 16 1.5 20 MB

13th generation Core i

edit

Desktop

edit

Underlined models feature vPro Enterprise and UDIMM ECC memory support when paired with a motherboard based on the W680 chipset.[10]

Core i5/i7/i9-13000 Series (Codenamed "Raptor Lake-S")
Processor
family 		Model Cores
(threads) 		Clock rate (GHz) Integrated
graphics 		Cache TDP (W) Price
(USD) 		Socket Launch
Base Turbo 2.0
Max. Turbo
Turbo max. 3.0
 GPU Boost clock
(GHz) 		EUs L2 cache Smart
cache 		Base Turbo
P E Total P E P E
Core i9 13900KS 8 (16) 16 (16) 24 (32) 3.2 2.4 5.4 4.3 6.0 5.8 1.65 GHz 32 32 MB 36 MB 150 253 $700 LGA 1700 January 12, 2023
13900K 3.0 2.2 5.4 4.3 5.8 5.7 125 $589 October 20, 2022
13900KF N/a $564
13900 2.0 1.5 5.2 4.2 5.6 5.5 UHD 770 1.65 GHz 32 65 219 $549 January 3, 2023
13900F N/a $524
13900T 1.1 0.8 5.1 3.9 5.3 UHD 770 1.65 GHz 32 35 106 $549
Core i7 13700K 8 (8) 16 (24) 3.4 2.5 5.3 4.2 5.4 1.6 GHz 24 MB 30 MB 125 253 $409 October 20, 2022
13700KF N/a $384
13790F 2.1 1.5 5.1 4.1 5.2 33 MB 65 219 China only February 8, 2023
13700 UHD 770 1.6 GHz 32 30 MB $384 January 3, 2023
13700F N/a $359
13700T 1.4 1.0 4.8 3.6 4.9 UHD 770 1.6 GHz 32 35 106 $384
Core i5 13600K 6 (12) 14 (20) 3.5 2.6 5.1 3.9 5.1 N/a 1.5 GHz 20 MB 24 MB 125 181 $319 October 20, 2022
13600KF N/a $294

Models in the table below are refreshed Alder Lake models.

Core i5/i3-13000 Series (Codenamed "Raptor Lake-S")
Processor
family 		Model Cores
(threads) 		Clock rate (GHz) Integrated
graphics 		Cache TDP (W) Price
(USD) 		Socket Launch
Base Turbo 2.0
Max. Turbo
 GPU Boost clock
(GHz) 		EUs L2 cache Smart
cache 		Base Turbo
P E Total P E P E
Core i5 13600 6 (12) 8 (8) 14 (20) 2.7 2.0 5.0 3.7 5.0 UHD 770 1.55 GHz 32 11.5 MB 24 MB 65 154 $255 LGA 1700 January 3, 2023
13600T 1.8 1.3 4.8 3.4 4.8 35 92
13500 2.5 1.8 3.5 65 154 $232
13500T 1.6 1.2 4.6 3.2 4.6 35 92
13400 4 (4) 10 (16) 2.5 1.8 3.3 UHD 730 1.55 GHz 24 9.5 MB 20 MB 65 154 $221
13400F N/a 148 $196
13400T 1.3 1.0 4.4 3.0 4.4 UHD 730 1.55 GHz 24 35 82 $221
13490F 2.5 1.8 4.8 3.5 4.8 N/a 24 MB 65 148 China only February 8, 2023
Core i3 13100 4 (8) N/a 4 (8) 3.4 N/a 4.5 N/a 4.5 UHD 730 1.5 GHz 24 5 MB 12 MB 60 89 $134 January 3, 2023
13100F N/a 58 $109
13100T 2.5 4.2 4.2 UHD 730 1.5 GHz 24 35 69 $134

Mobile

edit
Repurposed Desktop
edit

These parts are desktop processors repurposed for mobile use. All models are unlocked for overclocking. Underlined models feature vPro Enterprise and UDIMM ECC memory support when paired with a motherboard based on the mobile workstation WM790 chipset.

Core i7/i9-13000HX Series (Codenamed "Raptor Lake-HX")
Processor
family 		Model Cores (Threads) Clock (GHz) UHD
graphics 		Smart Cache TDP (W) Price
(USD) 		Launch
Base Clock Turbo Clock
P E Total P E P E EUs Boost Clock (GHz) Base Turbo
Core i9 13980HX 8 (16) 16 (16) 24 (32) 2.2 1.6 5.6 4.0 32 1.65 36 MB 55 W 157 W $668 January 4, 2023[11]
13950HX 5.5 $590
13900HX 5.4 3.9 $668
Core i7 13850HX 12 (12) 20 (28) 2.1 1.5 5.3 3.8 1.6 30 MB $428
13700HX 8 (8) 16 (24) 5.0 3.7 1.55 $485
13650HX 6 (12) 18 (20) 2.6 1.9 4.9 3.6 16 24 MB

The models in the table below are still desktop replacement parts, but they are based on the Alder Lake architecture and are refreshed for Raptor Lake.

Core i5-13000HX Series (Codenamed "Raptor Lake-HX")
Processor
family 		Model Cores (Threads) Clock (GHz) UHD
graphics 		Smart Cache TDP (W) Price
(USD) 		Launch
Base Clock Turbo Clock
P E P E P E EUs Boost Clock (GHz) Base Turbo
Core i5 13600HX 6 (12) 8 (8) 14 (20) 2.6 1.9 4.8 3.6 32 1.5 24 MB 55 W 157 W $284 January 4, 2023[12]
13500HX 2.5 1.8 4.7 3.5 $326
13450HX 4 (4) 16 2.4 4.6 3.4 16 1.45 20 MB


High Power
edit

Underlined models feature vPro Enterprise.

Core i5/i7/i9-13000H Series (Codenamed "Raptor Lake-H")
Processor
family 		Model Cores (Threads) Clock (GHz) Graphics Smart Cache TDP (W) Price
(USD) 		Launch
Base Clock Turbo Clock
P E P E P E EUs Boost Clock (GHz) Branding Base Turbo
Core i9 13900HK 6 (12) 8 (8) 14 (20) 2.6 1.9 5.4 4.1 96 1.5 Intel Iris Xe Graphics 24 MB 45 W 115 W $697 January 4, 2023[13]
13900H $617
Core i7 13800H 2.5 1.8 5.2 4.0 $457
13700H 2.4 5.0 3.7 $502
13620H 4 (4) 10 (16) 4.9 3.6 64 Intel UHD Graphics
Core i5 13600H 4 (8) 8 (8) 12 (16) 2.8 2.1 4.8 80 Intel Iris Xe Graphics 12 MB 95 W $311
13500H 2.6 1.9 4.7 3.5 1.45 $342
13420H 4 (4) 12 2.1 1.5 4.6 3.4 48 1.4 Intel UHD Graphics
High Power Thin and Light
edit

These CPUs are on the BGA1792 socket and are soldered to the motherboard.

Core i5/i7/i9-13005H Series (Codenamed "Raptor Lake-PX")}
Processor
family 		Model Cores (Threads) Clock Rate (GHz) Intel Iris Xe graphics Smart Cache TDP (W) Price
(USD) 		Launch
Base Clock Turbo Clock
P E Total P E P E EUs Boost Clock (GHz) Base Turbo
Core i9 13905H 6 (12) 8 (8) 14 (20) 2.6 1.9 5.4 4.1 96 1.5 24 MB 45 W 115 W $697 January 4, 2023[14]
Core i7 13705H 2.4 1.8 5.0 3.7 $502
Core i5 13505H 4 (8) 12 (16) 2.6 1.9 4.7 3.5 80 1.45 18 MB $342
Low Power Thin and Light
edit

Underlined models feature vPro Enterprise.

Core i5/i7-1300P Series (Codenamed "Raptor Lake-P")
Processor
family 		Model Cores (Threads) Clock Rate (GHz) Intel Iris
Xe graphics 		Smart Cache TDP (W) Price
(USD) 		Launch
Base Clock Turbo Clock
P E Total P E P E EUs Turbo Base Turbo
Core i7 1370P 6 (12) 8 (8) 14 (20) 1.9 1.4 5.2 3.9 96 1.5 24 MB 28 W 64 W $438 January 4, 2023[15]
1360P 4 (8) 12 (16) 2.2 1.6 5.0 3.7 18 MB $480
Core i5 1350P 1.9 1.4 4.7 3.5 80 12 MB $320
1340P 4.6 3.4 1.45 $353


Low Power
edit

Underlined models feature vPro Enterprise.

U300 & Core i3/i5/i7-1300U Series (Codenamed "Raptor Lake-U")
Processor
family 		Model Cores Clock Rate (GHz) Intel
Graphics 		Smart Cache TDP (W) Price
(USD) 		Launch
Base Clock Turbo Clock
P E Total P E P E EUs Boost Clock (GHz) Branding Base
Core i7 1365U 2 (4) 8 (8) 10 (12) 1.8 1.3 5.2 3.9 96 1.3 Intel Iris Xe Graphics 12 MB 15 W $426 January 4, 2023[16]
1355U 1.7 1.2 5.0 3.7 $469
Core i5 1345U 1.6 4.7 3.5 80 1.25 $309
1335U 1.3 0.9 4.6 3.4 $340
1334U
Core i3 1315U 4 (4) 6 (8) 1.2 4.5 3.3 64 Intel UHD Graphics 10 MB $309
1305U 1 (2) 5 (6) 1.6 1.2
Intel Processor U300 1.2 0.9 4.4 3.3 48 8 MB $193

12th generation Core I

edit

Underlined models support UDIMM ECC memory when paired with a W680 chipset.

Desktop

edit
Core i3/i5/i7/i9-12000/Pentium G7000/Celeron G6000 Series (Codenamed "Alder Lake-S")
Processor
family 		Model Cores (Threads) Clock rate (GHz) Integrated
graphics 		Cache TDP (W) Price
(USD) 		Socket Launch
Base Turbo GPU Max Clock EUs L2 cache Smart
cache 		Base Turbo
P E Total P E P E 3.0 TVB
Core i9 12900KS 8 (16) 8 (8) 16 (24) 3.4 2.5 5.2 4.0 5.3 5.5 UHD 770 1.55 GHz 32 14 MB 30 MB 150 241 $ 739 LGA 1700 Q1 2022
12900K 3.2 2.4 5.1 3.9 5.2 N/a 125 $ 589 Q4 2021
12900KF N/a $ 569
12900 2.4 1.8 5.0 3.8 5.1 UHD 770 1.55 GHz 32 65 202 $ 489 Q1 2022
12900F N/a $ 464
12900T 1.4 1.0 4.8 3.6 4.9 UHD 770 1.55 GHz 32 35 106 $ 489
Core i7 12700K 4 (4) 12 (20) 3.6 2.7 4.9 3.8 5.0 1.5 GHz 12 MB 25 MB 125 190 $ 409 Q4 2021
12700KF N/a $ 384
12700 2.1 1.6 4.8 3.6 4.9 UHD 770 1.5 GHz 32 65 180 $ 339 Q1 2022
12700F N/a $ 314
12700T 1.4 1.0 4.6 3.4 4.7 UHD 770 1.5 GHz 32 35 95 $ 339
Core i5 12600K 6 (12) 10 (16) 3.7 2.8 4.9 3.6 4.9 1.45 GHz 9.5 MB 20 MB 125 150 $ 289 Q4 2021
12600KF N/a $ 264
12600 N/a 6 (12) 3.3 N/a 4.8 N/a 4.8 UHD 770 1.45 GHz 32 7.5 MB 18 MB 65 117 $ 223 Q1 2022
12600T 2.1 4.6 4.6 35 74
12500 3.0 65 117 $ 202
12500T 2.0 4.4 4.4 35 74
12400 2.5 UHD 730 24 65 117 $ 192
12400F N/a $ 167
12400T 1.8 4.2 4.2 UHD 730 1.45 GHz 24 35 74 $ 192
Core i3 12300 4 (8) 4 (8) 3.5 4.4 N/a 5 MB 12 MB 60 89 $ 143
12300T 2.3 4.2 35 69
12100 3.3 4.3 60 89 $ 122
12100F N/a $ 97
12100T 2.2 4.1 UHD 730 1.45 GHz 24 35 69 $ 122
Pentium G7400 2 (4) 2 (4) 3.7 N/a UHD 710 1.35 GHz 16 2.5 MB 6 MB 46 N/a $ 64
G7400T 3.1 35
Celeron G6900 2 (2) 2 (2) 3.4 1.3 GHz 4 MB 46 $ 42
G6900T 2.8 35

Mobile

edit
Repurposed Desktop
edit

Underlined models support UDIMM ECC memory when paired with a WM690 chipset.

Core i5/i7/i9-12000HX Series (Codenamed "Alder Lake-HX")
Processor
family 		Model Cores (Threads) Clock rate (GHz) Integrated
graphics 		Cache TDP (W) Price
(USD) 		Launch
Base Turbo GPU Max Clock EUs L2 cache Smart
cache 		Base Turbo
P E Total P E P E
Core i9 12950HX 8 (16) 8 (8) 16 (24) 2.3 1.7 5.0 3.6 UHD 770 1.55 32 14 MB 30 MB 45 W 157 W $590 May 10, 2022
12900HX $688
Core i7 12850HX 2.1 1.5 4.8 3.4 1.45 25 MB $428
12800HX 2.0 $502
12650HX 6 (12) 14 (20) 4.7 3.3 11.5 MB 24 MB $472
Core i5 12600HX 4 (8) 12 (16) 2.5 1.8 4.6 1.35 9 MB 18 MB $284
12450HX 4 (4) 8 (12) 2.4 4.4 3.1 UHD 710 16 1.3 12 MB 12 MB $313
High Power
edit
Core i5/i7/i9-12000H Series (Codenamed "Alder Lake-H")
Processor
family 		Model Cores (Threads) Clock rate (GHz) Integrated
graphics 		Cache TDP (W) Price
(USD) 		Launch
Base Turbo Max Clock EUs L2 cache Smart
cache 		Base Turbo
P E Total P E P E
Core i9 12900HK 6 (12) 8 (8) 14 (20) 2.5 1.8 5.0 3.8 1.45 95 11.5 MB 24 MB 35 W 115 W $697 January 4, 2022
12900H $617
Core i7 12800H 2.4 4.8 3.7 1.4 $457
12700H 2.3 1.7 4.7 3.5 $502
12650H 4 (4) 10 (16) 64 5.5 MB
Core i5 12600H 4 (8) 8 (8) 12 (16) 2.7 2.0 4.5 3.3 80 9 MB 18 MB 95 W $311
12500H 2.5 1.8 1.3 $342
12450H 4 (4) 8 (12) 2.0 1.5 4.4 1.2 48 7 MB 12 MB
Balanced Power
edit
Core i3/i5/i7-1200P Series (Codenamed "Alder Lake-P")
Processor
family 		Model Cores (Threads) Clock rate (GHz) Integrated
graphics 		Cache TDP (W) Price
(USD) 		Launch
Base Turbo Max Clock EUs L2 cache Smart
cache 		Base Turbo
P E Total P E P E
Core i7 1280P 6 (12) 8 (8) 14 (20) 1.8 1.3 4.8 3.6 1.45 96 11.5 MB 24 MB 28 W 64 W $482 February 23, 2022
1270P 4 (8) 12 (16) 2.2 1.6 3.5 1.4 9 MB 18 MB $438
1260P 2.1 1.5 4.7 3.4 $480
Core i5 1250P 1.7 1.2 4.4 3.3 80 12 MB $320
1240P 1.3 $353
Core i3 1220P 2 (4) 10 (12) 1.5 1.1 1.1 64 7.5 MB $309
Low Power
edit
Core i3/i5/i7-1205U Series (Codenamed "Alder Lake-U15")
Processor
family 		Model Cores (Threads) Clock rate (GHz) Integrated
graphics 		Cache TDP (W) Price
(USD) 		Launch
Base Turbo Max Clock EUs L2 cache Smart
cache 		Base Turbo
P E Total P E P E
Core i7 1265U 2 (4) 8 (8) 10 (12) 1.8 1.3 4.8 3.6 1.25 96 7.5 MB 12 MB 15 W 55 W $426 February 23, 2022
1255U 1.7 1.2 4.7 3.5
Core i5 1245U 1.6 1.2 4.4 3.3 1.2 80 $309
1230U 1.3 0.9
Core i3 1215U 4 (4) 6 (8) 1.2 1.1 64 4.5 MB 10 MB $281
Pentium 8505 1 (2) 5 (6) 0.9 48 3.125 8 MB $161
Celeron 7305 1 (1) 5 (5) N/a $107
Ultra Low Power
edit
Core i3/i5/i7-1200U Series (Codenamed "Alder Lake-U9")
Processor
family 		Model Cores (Threads) Clock rate (GHz) Integrated
graphics 		Cache TDP (W) Price
(USD) 		Launch
Base Turbo Max Clock EUs L2 cache Smart
cache 		Base Turbo
P E Total P E P E
Core i7 1260U 2 (4) 8 (8) 10 (12) 1.1 0.8 4.7 3.5 0.9 96 7.5 MB 12 MB 9 W 28 W $426 February 23, 2022
1250U
Core i5 1240U 1.1 4.4 3.3 0.9 80 $309
1230U 1.0 0.7
Core i3 1210U 4 (4) 6 (8) 1.0 0.85 64 4.5 MB 10 MB $281
Pentium 8505 1 (2) 5 (6) 0.7 48 3.125 8 MB $161
Celeron 7305 1 (1) 5 (5) N/a $107
Value
edit

These processors are E-core only.

N-Series (Codenamed "Alder Lake-N")
Processor
family 		Model Cores (Threads) Clock rate (GHz) Integrated
graphics 		Smart Cache TDP (W) Price
(USD)
Base Turbo EUs Max Clock Down Base
Core i3 N305 8 (8) 1.8 3.8 32 1.25 6 MB 9 W 15 W $309
N300 0.8 Unknown 7 W
Intel Processor N200 4 (4) 1.0 3.7 0.75 0.1 W 6 W $193
N100 0.8 3.4 24 Unknown $55
N97 2.0 3.6 1.2 12 W $128
N95 1.7 3.4 16 15 W Unknown
N50 2 (2) 1.0 3.4 0.75 6 W $128
Atom x7000E Series (Codenamed "Alder Lake-N")
Processor
family 		Model Cores (Threads) Clock rate (GHz) Integrated
graphics 		Smart Cache TDP (W) Price
(USD)
Base Turbo EUs Max Clock Base
Atom x7425E 4 (4) 1.5 3.4 24 1.0 6 MB 12 W $58
x7213E 2 (2) 1.7 3.2 16 10 W $47
x7211E 1.0 6 W $39

11th generation Core i

edit

Released on September 2, 2020, 11th generation Intel Core i processors consisted of two separate architectures. Desktop processors were based on Rocket Lake which released on March 30, 2021 while mobile processors were based on Tiger Lake and launched on September 2, 2020.

Desktop

edit

Rocket Lake based desktop parts are based on the Cypress Cove architecture, a 14nm backport of the 10nm Sunny Cove (microarchitecture) architecture.

Core i5/i7/i9-11000 Series (Codenamed "Rocket Lake-S")
Processor
family 		Model Cores
(threads) 		Clock rate (GHz) iGPU Smart
cache 		TDP Price
(USD) 		Socket Launch
Base Turbo
All Core 2.0 3.0 GPU Max Clock (GHz) EUs
Core i9 11900K 8 (16) 3.5 4.8 5.1 5.2 UHD 750 1.3 32 16 MB 125 W $ 539 LGA 1200 March 30, 2021
11900KF N/a $ 513
11900 2.5 4.7 5.0 5.1 UHD 750 1.3 32 65 W $ 439
11900F N/a $ 422
11900T 1.5 3.7 4.8 4.9 UHD 750 1.3 32 35 W $ 439
Core i7 11700K 3.6 4.6 4.9 5.0 125W $ 399
11700KF N/a $ 374
11700 2.5 4.4 4.8 4.9 UHD 750 1.3 32 65W $ 323
11700F N/a $ 298
11700T 1.4 3.6 4.5 4.6 UHD 750 1.3 32 35 W $ 323
Core i5 11600K 6 (12) 3.9 4.6 4.9 N/a 12 MB 125 W $ 262
11600KF N/a $ 237
11600 2.8 4.3 4.8 UHD 750 1.3 32 65 W $ 213
11600T 1.7 3.5 4.1 35 W
11500 2.7 4.2 4.6 65 W $ 192
11500T 1.5 3.4 3.9 1.2 35 W
11400 2.6 4.2 4.4 UHD 730 1.3 24 65 W $ 182
11400F N/a $ 157
11400T 1.3 3.3 3.7 UHD 730 1.2 24 35 W $ 182

Mobile

edit

These models are based on the Tiger Lake architecture which uses the 10nm Willow Cove microarchitecture. They have a configurable TDP which changes the base clock.

High Power
edit

These processors are designed mobile workstations and support Intel vPro.

Xeon W-11055M Series (Codenamed "Tiger Lake-H")
Processor
family 		Model Cores
(threads) 		Clock rate (GHz) iGPU Smart
cache 		TDP Price
(USD) 		Launch
Base Turbo
Min Max All Core Max GPU Max Clock (GHz) EUs Min Max
Xeon W 11955M 8 (16) 2.1 2.6 4.5 5.0 UHD 770 1.45 32 24 MB 35 W 45 W $623 September 2, 2020
11855M 6 (12) 2.6 3.2 4.4 4.9 18 MB $450

Underlined models support Intel vPro.

Core i5/i7/i9-11000H Series (Codenamed "Tiger Lake-H")
Processor
family 		Model Cores
(threads) 		Clock rate (GHz) iGPU Smart
cache 		TDP Price
(USD) 		Launch
Base Turbo
Min Max All Core Max GPU Max Clock (GHz) EUs Min Max
Core i9 11980HK 8 (16) 2.6 3.3 4.5 5.0 UHD 770 1.45 32 24 MB 45 W 65 W $583 September 20, 2020
11950H 2.1 2.6 35 W 45 W $623
11900H 2.5 4.4 4.9 $546
Core i7 11850H 4.3 4.8 $395
11800H 1.9 2.3 4.2 4.6 May 11, 2021
11600H 6 (12) 2.5 2.9 4.6 18 MB July 15, 2021
Core i5 11500H 2.4 2.9 4.2 4.6 12 MB $250 May 11, 2021
11400H 2.2 2.7 4.1 4.5 UHD 710 16
11260H 2.1 2.6 4.0 4.4 1.4
High Power Thin and Light
edit
Core i5/i7-11300H Series (Codenamed "Tiger Lake-H35")
Processor
family 		Model Cores
(threads) 		Clock rate (GHz) iGPU Smart
cache 		TDP Price
(USD) 		Launch
Base Turbo
Min Max All Core Max GPU Max Clock (GHz) EUs Min Max
Core i7 11390H 4 (8) 2.9 3.4 4.6 5.0 Iris Xe Graphics 1.4 96 12 MB 28 W 35 W $426 June 21, 2021
11375H 3.0 3.3 4.3 1.35 $482 January 11, 2021
11370H 4.8 $426
Core i5 11320H 2.5 3.2 4.5 8 MB $309 June 21, 2021
11300H 2.6 3.1 4.0 4.4 1.3 80 January 11, 2021


Low Power
edit

These models support DDR4-3200 and LPDDR4X-4267 memory. Underlined models support Intel vPro.

Core i5/i7-1105G7 Series (Codenamed "Tiger Lake-UP3")
Processor
family 		Model Cores
(threads) 		Clock rate (GHz) iGPU Smart
cache 		TDP Price
(USD) 		Launch
Base Turbo
Min Max All Core Max GPU Max Clock (GHz) EUs Min Max
Core i7 1195G7 4 (8) 1.3 2.9 4.6 5.0 Iris Xe G7 1.4 96 12 MB 12 W 28 W May 20, 2021 $426
1185G7 1.2 3.0 4.3 4.8 1.35 September 2, 2020
1165G7 2.8 4.1 4.7 1.3
Core i5 1155G7 1.0 2.5 4.3 4.5 1.35 80 8 MB May 20, 2021 $309
1145G7 1.1 2.6 3.8 4.4 1.3 January 11, 2021
1135G7 0.9 2.4 4.2 September 20, 2020

These models support DDR4-3200 and LPDDR4X-3733 memory. Underlined models support Intel vPro.

Core i3-1105G4/Pentium Gold 7505/Celeron 6305 Series (Codenamed "Tiger Lake-UP3")
Processor
family 		Model Cores
(threads) 		Clock rate (GHz) iGPU Smart
cache 		TDP Price
(USD) 		Launch
Base Turbo
Min Max All Core Max GPU Max Clock (GHz) EUs Min Max
Core i3 1125G4 4 (8) 0.9 2.0 3.3 3.7 UHD G4 1.25 48 8 MB 12 W 28 W $281 September 2, 2020
1115G4 2 (4) 1.7 3.0 4.1 6 MB
Pentium Gold 7505 2.0 3.5 4 MB 15 W $161
Celeron 6505 2 (2) 1.8 N/a $107
Ultra Low Power
edit

These models support LPDDR4X-4267 memory. Underlined models support Intel vPro.

Core i3/i5/i7-1100G7/G4 Series (Codenamed "Tiger Lake-UP4")
Processor
family 		Model Cores
(threads) 		Clock rate (GHz) iGPU Smart
cache 		TDP Price
(USD) 		Launch
Base Turbo
Min Max All Core Max GPU Max Clock (GHz) EUs Min Max
Core i7 1180G7 4 (8) 0.9 2.2 3.7 4.6 Iris Xe G7 1.1 96 12 MB 7 W 15 W $426 January 11, 2021
1160G7 2.1 3.6 4.4 September 2, 2020
Core i5 1140G7 0.8 1.8 4.2 80 8 MB $309 January 11, 2021
1130G7 3.4 4.0 September 2, 2020
Core i3 1120G4 1.5 3.0 3.5 UHD G4 48 $281
1110G4 2 (4) 1.5 2.5 3.9 6 MB

10th generation Core i

edit

Desktop (codenamed "Comet Lake")

edit

Pentium and Celeron CPUs lack AVX and AVX2 support.

Processor
branding 		Model Cores Threads CPU clock rate (GHz) GPU Smart
cache
(L3) 		TDP Memory
support 		Price
(USD)[a]
Base Turbo Boost Model Max clock
rate (GHz)
All-Core 2.0 3.0 TVB Base Down

Core i9 10900K 10 20 3.7 4.8 5.1 5.2 5.3 UHD 630 1.20 20 MB[b] 125 W 95 W DDR4-2933
up to 128 GB 		$488
10900KF N/a $472
10910 3.6 4.7 5.0 N/a N/a UHD 630 1.2 OEM
10900 2.8 4.5 5.1 5.2 65 W N/a $438
10900F N/a $422
10900T 1.9 3.7 4.5 4.6 N/a UHD 630 1.2 35 W 25 W $438
10850K 3.6 4.8 5.0 5.1 5.2 125 W 95 W $453
Core i7 10700K 8 16 3.8 4.7 N/a 16 MB $374
10700KF N/a $349
10700 2.9 4.6 4.7 4.8 UHD 630 1.2 65 W N/a $323
10700F N/a $298
10700T 2.0 3.7 4.4 4.5 UHD 630 1.2 35 W 25 W $325
Core i5 10600K 6 12 4.1 4.5 4.8 N/a 12 MB 125 W 95 W DDR4-2666
up to 128 GB 		$262
10600KF N/a $237
10600 3.3 4.4 4.8 UHD 630 1.2 65 W N/a $213
10600T 2.4 3.7 4.0 35 W 25 W
10500 3.1 4.2 4.5 1.15 65 W N/a $192
10500T 2.3 3.5 3.8 35 W 25 W
10400 2.9 4.0 4.3 1.1 65 W N/a $182
10400F N/a $157
10400T 2.0 3.2 3.6 UHD 630 1.1 35 W 25 W $182
Core i3 10320 4 8 3.8 4.4 4.6 1.15 8 MB 65 W N/a $154
10300 3.7 4.2 4.4 $143
10300T 3.0 3.6 3.9 1.1 35 W 25 W
10100 3.6 4.1 4.3 6 MB 65 W N/a $122
10100F N/a $79
10100T 3.0 3.5 3.8 UHD 630 1.1 35 W 25 W $122
Pentium
Gold 		G6600 2 4 4.2 N/a 4 MB 58 W N/a $86
G6500 4.1 $75
G6500T 3.5 1.05 35 W 25 W
G6400 4.0 UHD 610 58 W N/a $64
G6400T 3.4 35 W 25 W
Celeron G5925 2 2 3.6 58 W N/a $52
G5920 3.5 2 MB
G5905 4 MB $42
G5905T 3.3 1.0 35 W 25 W
G5900 3.4 1.05 2 MB 58 W N/a
G5900T 3.2 1.0 35 W 25 W
  1. ^ a b c d Price is Recommended Customer Price (RCP) at launch. RCP is the trade price that processors are sold by Intel to retailers and OEMs. Actual MSRP for consumers is higher
  2. ^ Transistorized memory, such as RAM, ROM, flash and cache sizes as well as file sizes are specified using binary meanings for K (10241), M (10242), G (10243), etc.

Mobile (codenamed "Comet Lake", "Ice Lake", and "Amber Lake")

edit
Processor
family 		Model Cores Threads Clock rate (GHz) Cache IGP TDP Code­name Socket Release
Base Max. turbo L1 L2 L3 Processor Clock rate (MHz)
Base Max. dynamic
Core i7 10750H 6 12 2.60 5.00 384KB 1.5MB 12MB UHD 350 1150 45 W Comet Lake BGA 1440 Q1 2020
10710U 1.10 4.70 300 15 W BGA 1528 Q3 2019
1065G7 4 8 1.30 3.90 256KB 1MB 8MB Iris Plus 1100 Ice Lake BGA 1526
10610U 1.80 4.90 UHD 1150 Comet Lake BGA 1528 Q2 2020
1060G7 1.00 3.80 Iris Plus 1100 9 W Ice Lake BGA 1377 Q3 2019
10510U 1.80 4.90 UHD 1150 15 W Comet Lake BGA 1528
10510Y 1.20 4.50 7 W Amber Lake Y BGA 1377
Core i5 10500H 6 12 2.50 384KB 1.5MB 12MB 350 1050 45 W Comet Lake BGA 1440 Q4 2020
10300H [17] 4 8 256KB 1MB 8MB
10210U 1.60 4.20 6MB UHD 620 300 1100 15 W BGA 1528 Q3 2019
Core i3 10110Y 2 4 1.00 4.00 128KB 512KB 4MB UHD 615 1000 7 W Amber Lake Y BGA 1377
1005G1 1.20 3.40 UHD G1 900 15 W Ice Lake BGA 1526

9th generation Core i

edit

Desktop (codenamed "Coffee Lake Refresh")

edit
Processor
family 		Model Cores Threads Clock rate (GHz) Cache IGP TDP Code­name Socket Release
Base Max. turbo L1 L2 L3 processor Clock rate (MHz)
Base Max. dynamic
Core i9 9900KS 8 16 4.00 5.00 512KB 2MB 16MB UHD 630 350 1200 127 W Coffee Lake LGA 1151 Q4 2019
9900K 3.60 95 W Q4 2018
9900 3.10 65 W Q2 2019
9900T 2.10 4.40 35 W
Core i7 9700K 8 3.60 4.90 12MB 95 W Q4 2018
9700KF N/a N/a N/a Q1 2019
9700 3.00 4.70 UHD 630 350 1200 65 W Q2 2019
9700F N/a N/a N/a
9700E 2.60 4.40 UHD 630 350 1150
9700T 2.00 4.30 1200 35 W
9700TE 1.80 3.80 1150
Core i5 9600K 6 6 3.70 4.60 384KB 1.5MB 9MB 95 W Q4 2018
9600KF N/a N/a N/a Q1 2019
9600 3.10 UHD 630 350 1150 65 W Q2 2019
9600T 2.30 3.90 35 W
9500 3.00 4.40 1100 65 W
9500F N/a N/a N/a
9500E 4.20 UHD 630 350 1100
9500T 2.20 3.70 35 W
9500TE 3.60
9400 2.90 4.10 1050 65 W
9400F N/a N/a N/a Q1 2019
9400T 1.80 3.40 UHD 630 350 1050 35 W Q2 2019
Core i3 9350K 4 4 4.00 4.60 256KB 1MB 8MB 1150 91 W Q1 2019
9350KF N/a N/a N/a
9320 3.70 4.40 UHD 630 350 1150 65 W Q2 2019
9300 4.30
9300T 3.20 3.80 1100 35 W
9100 3.60 4.20 6MB 65 W
9100E 3.10 3.70 1050
9100F 3.60 4.20 N/a N/a N/a 65 W
9100T 3.10 3.70 UHD 630 350 1100 35 W
9100TE 2.20 3.20 1050

8th generation Core i

edit

Desktop (codenamed "Coffee Lake")

edit
Processor
family 		Model Cores Threads Clock rate (GHz) Cache IGP TDP Code­name Socket Release
Base Max. turbo L1 L2 L3 Processor Clock rate (MHz)
Base Max. dynamic
Core i7 8086K 6 12 4.00 5.00 384KB 1.5MB 12MB UHD 630 350 1200 95 W Coffee Lake LGA 1151 Q2 2018
8700K 3.70 4.70 Q4 2017
8700 3.20 4.60 65 W
8700T[18] 2.40 4.00 35 W Q2 2018
Core i5 8600K 6 3.60 4.30 9MB 1150 95 W Q4 2017
8600 3.10 65 W Q1 2018
8600T 2.30 3.70 35 W Q2 2017
8500 3.00 4.10 1100 65 W Q2 2018
8500T[19] 2.10 3.50 35 W
8400 2.80 4.00 1050 65 W Q4 2017
8400T 1.70 3.30 35 W Q2 2018
Core i3 8350K 4 4 4.00 N/a 256KB 1MB 8MB 1150 91 W Q4 2017
8100 3.60 6MB 1100 65 W
8100T[20] 3.10 35 W Q2 2018

Mobile (codenamed "Coffee Lake", "Amber Lake" and "Whiskey Lake")

edit
Processor
family 		Model Cores Threads Clock rate (GHz) Cache IGP TDP Code­name Socket Release
base max turbo L1 L2 L3 Processor Clock rate (MHz)
Base Max. dynamic
Core i9 8950HK 6 12 2.90 4.80 384KB 1.5MB 12MB UHD 630 350 1200 45 W Coffee Lake BGA 1440 Q2 2018
Core i7 8850H 2.60 4.30 9MB 1150
8750H 2.20 4.10 1100
8700B 3.20 4.60 12MB 1200 65 W
8665U 4 8 1.90 4.80 256KB 1MB 8MB UHD 620 300 1150 15 W Whiskey Lake BGA 1528 Q2 2019
8650U 1.90 4.20 Kaby Lake R BGA 1356 Q3 2017
8569U 2.80 4.70 Iris Plus 655 1200 28 W Coffee Lake BGA 1528 Q2 2019
8565U 1.80 4.60 UHD 620 1150 15 W Whiskey Lake Q3 2018
8559U 2.70 4.50 Iris Plus 655 1200 28 W Coffee Lake Q2 2018
8557U 1.70 Iris Plus 645 1150 15 W Q3 2019
8550U 1.80 4.00 UHD 620 Kaby Lake R BGA 1356 Q3 2017
8500Y 2 4 1.50 4.20 128KB 512KB 4MB UHD 615 1050 5 W Amber Lake Y BGA 1515 Q1 2019
Core i5 8500B 6 6 3.00 4.10 384KB 1.5MB 9MB UHD 630 350 1100 65 W Coffee Lake BGA 1440 Q2 2018
8400H 4 8 2.50 4.20 256KB 1MB 8MB 45 W
8400B 6 6 2.80 4.00 384KB 1.5MB 9MB 1050 65 W
8365U 4 8 1.60 4.10 256KB 1MB 6MB UHD 620 300 1100 15 W Whiskey Lake BGA 1528 Q2 2019
8350U 1.70 3.60 Kaby Lake R BGA 1356 Q3 2017
8310Y 2 4 1.60 3.90 128KB 512KB 4MB UHD 617 1050 7 W Amber Lake Y BGA 1515 Q1 2019
8300H 4 8 2.30 4.00 256KB 1MB 8MB UHD 630 350 1000 45 W Coffee Lake BGA 1440 Q2 2018
8279U 2.40 4.10 6MB Iris Plus 655 300 28 W Q2 2019
8269U 2.60 4.20 Iris Plus 655 1100 BGA 1528 Q2 2018
8265U 1.60 3.90 UHD 620 15 W Whiskey Lake Q3 2018
8260U Coffee Lake Q4 2019
8259U 2.30 3.80 Iris Plus 655 1050 28 W Q2 2018
8257U 1.40 3.90 Iris Plus 645 15W Q3 2019
8250U 1.60 3.40 UHD 620 1100 Kaby Lake R BGA 1356 Q3 2017
8210Y 2 4 3.60 128KB 512KB 4MB UHD 617 1050 7 W Amber Lake Y BGA 1515 Q1 2019
8200Y 1.30 3.90 UHD 615 950 5 W Q3 2018
Core i3 8145U 2.10 UHD 620 1000 15 W Whiskey Lake BGA 1528
8140U 2.10 Coffee Lake Q4 2019
8130U 2.20 3.40 Kaby Lake R BGA 1356 Q1 2018
8109U 3.00 3.60 Iris Plus 655 1050 28 W Coffee Lake BGA 1528 Q2 2018
8100H 4 3.00 N/a 256KB 1MB 6MB UHD 630 350 1000 45 W BGA 1440 Q3 2018
8100B 3.60 1050 65 W
Core m3 8100Y 2 1.10 3.40 128KB 512KB 4MB UHD 615 300 900 5 W Amber Lake Y BGA 1515

7th generation Core i

edit

Desktop (codenamed "Kaby Lake" and "Skylake-X")

edit
Processor
family 		Model Cores Threads Clock rate (GHz) Cache IGP TDP Code­name Socket Release
Base Max. turbo L1 L2 L3 Processor Clock rate (MHz)
Base Max. dynamic
Core i9 7980XE 18 36 2.60 4.20 1.15MB 18MB 24.75MB N/a N/a N/a 165 W Skylake LGA 2066 Q3 2017[21]
7960X 16 32 2.80 1MB 16MB 22MB
7940X 14 28 3.10 4.30 896KB 14MB 19.25MB
7920X 12 24 2.90 768KB 12MB 16.50MB 140 W
7900X 10 20 3.30 640KB 10MB 13.75MB Q2 2017
Core i7 7820X 8 16 3.60 512KB 8MB 11MB
7800X 6 12 3.50 4.00 384KB 6MB 8.25MB
7740X 4 8 4.30 4.50 256KB 1MB 8MB 112 W Kaby Lake Q1 2017
7700K 4.20 HD 630 350 1150 91 W LGA 1151
7700 3.60 4.20 65 W
7700T 2.90 3.80 35 W
Core i5 7640X 4 4.00 4.20 6MB N/a N/a N/a 112 W LGA 2066
7600K 3.80 HD 630 350 1150 91 W LGA 1151
7600 3.50 4.10 65 W
7600T 2.80 3.70 1100 35 W
7500 3.40 3.80 65 W
7500T 2.70 3.30 35 W
7400 3.00 3.50 1000 65 W
7400T 2.40 3.00 35 W
Core i3 7350K 2 4.20 N/a 128KB 512KB 4MB 1150 60 W
7320 4.10 51 W
7300 4.00
7300T 3.50 1100 35 W
7100 3.90 3MB 51 W
7100T 3.40 35 W
7101E 3.90 54 W
7101TE 3.40 35 W
Pentium G4620 3.70 51 W
G4600 3.60
G4600T 3.00 1050 35 W
G4560 3.50 HD 610 54 W
G4560T 2.90 35 W
Celeron G3950 2 3.00 2MB 51 W
G3930 2.90
G3930T 2.70 1000 35 W

Mobile (codenamed "Kaby Lake" and "Apollo Lake")

edit
Processor
family 		Model Cores Threads Clock rate (GHz) Cache IGP TDP Code­name Socket Release
Base Max. turbo L1 L2 L3 Processor Clock rate (MHz)
Base Max. dynamic
Core i7 7920HQ 4 8 3.10 4.10 256KB 1MB 8MB HD 630 350 1100 45 W Kaby Lake BGA 1440 Q1 2017
7820HQ 2.90 3.90
7820HK
7700HQ 2.80 3.80 6MB
7660U 2 4 2.50 4.00 128KB 512KB 4MB Iris Plus 640 300 15 W BGA 1356
7600U 2.80 3.90 HD 620 1150 Q3 2016
7567U 3.50 4.00 Iris Plus 650 28 W
7560U 2.40 3.80 Iris Plus 640 1050 15 W Q1 2017
7500U 2.70 3.50 HD 620
7Y75 1.30 3.60 HD 615 4.5 W BGA 1515
Core i5 7440HQ 4 2.80 3.80 256KB 1MB 6MB HD 630 350 1000 45 W BGA 1440
7300HQ 2.50 3.50
7360U 2 2.30 3.60 128KB 512KB 4MB Iris Plus 640 300 15 W BGA 1356
7300U 2.60 3.50 3MB HD 620 1100
7287U 3.30 3.70 4MB Iris Plus 650 28 W
7267U 3.10 3.50 1050
7260U 2.20 3.40 Iris Plus 640 950 15 W
7200U 2.50 3.10 3MB HD 620 1000 Q3 2016
7Y57 1.20 3.30 4MB HD 615 950 4.5 W BGA 1515 Q1 2017
7Y54 3.20
Core i3 7100H 3.00 N/a 3MB HD 630 350 35 W BGA 1440
7167U 2.80 Iris Plus 650 300 1000 28 W BGA 1356
7130U 2.70 HD 620 15 W Q2 2017
7100U 2.40 Q3 2016
Core m3 7Y32 1.10 3.00 4MB HD 615 900 4.5 W BGA 1515 Q2 2017
7Y30 1.00 2.60 Q3 2016
Pentium N4200 4 1.10 2.50 224KB 2MB N/a HD 505 200 750 6 W BGA 1296
4415U 2 2.30 N/a 128KB 512KB 2MB HD 610 300 950 15 W BGA 1356 Q1 2017
4415Y 1.60 HD 615 850 6 W BGA 1515 Q2 2017
4410Y 1.50 256KB 1MB Q1 2017
Celeron N3450 4 1.10 2.20 224KB 2MB N/a HD 500 200 700 Apollo Lake BGA 1296 Q3 2016
N3350 2 2 2.40 112KB 650
3965U 2.20 N/a 128KB 512KB 2MB HD 610 300 900 15 W Kaby Lake BGA 1356 Q1 2017
3865U 1.80

6th generation Core i

edit

Desktop (codenamed "Skylake")

edit

Mainstream desktop processors

edit

Common features of the mainstream desktop Skylake CPUs:

  • DMI 3.0 and PCIe 3.0 interfaces
  • Dual-channel memory support in the following configurations: DDR3L-1600 1.35 V (32 GB maximum) or DDR4-2133 1.2 V (64 GB maximum). DDR3 is unofficially supported through some motherboard vendors[22][23][24]
  • 16 PCIe 3.0 lanes
  • The Core-branded processors support the AVX2 instruction set. The Celeron and Pentium-branded ones only support up to SSE4.2
  • 350 MHz base graphics clock rate
Processor
branding
and model 		Cores
(threads) 		Clock rate (GHz) GPU Cache TDP Socket Release
date 		Release
price
(USD)
Base Turbo Boost 2.0 Model EUs Max
freq.
(GHz) 		L1 L2 L3 L4
(eDRAM)
1 2 [citation needed] 4 [citation needed]

Core i7 6700K 4 (8) 4.0 4.2 4.0 HD 530 24 1.15[25] 256KB 1MB 8MB N/a 91 W LGA 1151 August 5, 2015 $339
6785R 3.3 3.9 3.8 3.5 Iris Pro 580 72 128 MB 65 W BGA 1440 May 3, 2016 $370
6700 3.4 4.0 3.9 3.7 HD 530 24 N/a LGA 1151 September 1, 2015 $303
6700T 2.8 3.6 3.5 3.4 35 W
Core i5 6600K 4 (4) 3.5 3.9 3.8 3.6 6MB 91 W August 5, 2015 $242
6685R 3.2 3.8 3.7 3.3 Iris Pro 580 72 128 MB 65 W BGA 1440 May 3, 2016 $288
6600 3.3 3.9 3.8 3.6 HD 530 24 N/a LGA 1151 September 1, 2015 $213
6585R 2.8 3.6 3.5 3.1 Iris Pro 580 72 1.1 128 MB BGA 1440 May 3, 2016 $255
6500 3.2 3.3 HD 530 24 1.05 N/a LGA 1151 September 1, 2015 $192
6600T 2.7 3.5 3.4 1.1 35 W Q3 2015 $213
6500T 2.5 3.1 3.0 2.8 $192
6402P 2.8 3.4 3.2 HD 510 12 0.95 65 W December 27, 2015 $182
6400T 2.2 2.8 2.7 2.5 HD 530 24 35 W Q3 2015
6400 2.7 3.3 3.1 65 W August 5, 2015
Core i3 6320 2 (4) 3.9 N/a 1.15 128KB 512KB 4MB 51 W Q3 2015 $149
6300 3.8 $138
6100 3.7 1.05 3 MB October 2015 $117
6300T 3.3 0.95 4 MB 35 W $138
6100T 3.2 3 MB $117
6098P 3.6 HD 510 12 1.050 54 W December 27, 2015
Pentium G4520 2 (2) HD 530 24 51 W October 2015 $86
G4500 3.5 $75
G4500T 3.0 0.95 35 W Q3 2015
G4400 3.3 HD 510 12 1.0 54 W October 2015 $64
G4400T 2.9 0.95 35 W Q3 2015
G4400TE 2.4 Q4 2015 $70
Celeron G3920 2.9 2 MB 51 W $52
G3900 2.8 $42
G3900TE 2.3 35 W
G3900T 2.6

Mobile processors

edit

For mobile workstation processors, see Server processors.

Processor
branding and
model 		Cores
(threads) 		CPU
clock
rate 		CPU Turbo clock rate GPU GPU clock rate Cache TDP cTDP Release date Price
(USD)
Single
core 		Dual
core [citation needed] 		Quad
core [citation needed] 		Base Turbo L1 L2 L3 L4
(eDRAM) 		Up Down

Core i7 6970HQ 4 (8) 2.8 GHz 3.7 GHz ? Iris Pro 580 350 MHz 1050 MHz 256KB 1MB 8MB 128MB 45 W N/a 35 W Q1 2016 $623
6920HQ 2.9 GHz 3.8 GHz 3.6 GHz 3.4 GHz HD 530 N/a September 1, 2015 $568
6870HQ 2.7 GHz 3.6 GHz ? Iris Pro 580 1000 MHz 128MB Q1 2016 $434
6820HQ 3.4 GHz 3.2 GHz HD 530 1050 MHz N/a September 1, 2015 $378
6820HK
6770HQ 2.6 GHz 3.5 GHz ? Iris Pro 580 950 MHz 6MB 128MB Q1 2016 $434
6700HQ 3.3 GHz 3.1 GHz HD 530 1050 MHz N/a September 1, 2015 $378
6660U 2 (4) 2.4 GHz 3.4 GHz 3.2 GHz N/a Iris 540 300 MHz 128KB 512KB 4MB 64MB 15 W 9.5 W Q1 2016 $415
6650U 2.2 GHz Q3 2015
6600U 2.6 GHz N/a HD 520 N/a 25 W 7.5 W September 1, 2015 $393
6567U 3.3 GHz 3.6 GHz 3.4 GHz Iris 550 1100 MHz 64MB 28 W N/a 23 W Q3 2015 TBD
6560U 2.2 GHz 3.2 GHz 3.1 GHz Iris 540 1050 MHz 15 W 9.5 W
6500U 2.5 GHz 3.1 GHz 3.0 GHz HD 520 N/a 7.5 W September 1, 2015 $393
Core i5 6440HQ 4 (4) 2.6 GHz 3.5 GHz 3.3 GHz 3.1 GHz HD 530 350 MHz 950 MHz 256KB 1MB 6MB 45 W 35 W $250
6360U 2 (4) 2.0 GHz 3.1 GHz 2.9 GHz N/a Iris 540 300 MHz 1000 MHz 128KB 512KB 4MB 64MB 15 W 9.5 W Q3 2015 $304
6350HQ 4 (4) 2.3 GHz 3.2 GHz ? Iris Pro 580 350 MHz 900 MHz 256KB 1MB 6MB 128MB 45 W 35 W Q1 2016 $306
6300HQ 3.0 GHz 2.8 GHz HD 530 950 MHz N/a September 1, 2015 $250
6300U 2 (4) 2.4 GHz 3.0 GHz 2.9 GHz N/a HD 520 300 MHz 1000 MHz 128KB 512KB 3MB 15 W 7.5 W $281
6287U 3.1 GHz 3.5 GHz 3.3 GHz Iris 550 1100 MHz 4MB 64MB 28 W 23 W Q3 2015 $304
6267U 2.9 GHz 3.3 GHz 3.1 GHz 1050 MHz 23 W
6260U 1.8 GHz 2.9 GHz 2.7 GHz Iris 540 950 MHz 15 W 9.5 W $304
6200U 2.3 GHz 2.8 GHz HD 520 1000 MHz 3MB N/a 7.5 W September 1, 2015 $281
Core i3 6167U 2.7 GHz N/a N/a Iris 550 64MB 28 W 23 W Q3 2015 $304
6157U 2.4 GHz Q3 2016
6100H 2.7 GHz HD 530 350 MHz 900 MHz N/a 35 W N/a September 1, 2015 $225
6100U 2.3 GHz HD 520 300 MHz 1000 MHz 15 W 7.5 W $281
6006U 2.0 GHz 900 MHz N/a November, 2016 $281
Core m7 6Y75 1.2 GHz 3.1 GHz 2.9 GHz HD 515 300 MHz 1000 MHz 4MB 4.5 W 7 W 3.5 W September 1, 2015 $393
Core m5 6Y57 1.1 GHz 2.8 GHz 2.4 GHz 900 MHz $281
6Y54 2.7 GHz
Core m3 6Y30 0.9 GHz 2.2 GHz 2.0 GHz 850 MHz 3.8 W
Pentium 4405U 2.1 GHz N/a N/a HD 510 950 MHz 2MB 15 W N/a 10 W Q3 2015 $161
4405Y 1.5 GHz HD 515 800 MHz 6 W 4.5 W
Celeron G3902E 2 (2) 1.6 GHz N/a HD 510 350 MHz 950 MHz 25 W N/a Q1 2016 $107
G3900E 2.4 GHz 35 W
3955U 2.0 GHz 300 MHz 900 MHz 15 W 10 W Q4 2015
3855U 1.6 GHz

All processors

edit

All processors are listed in chronological order.

The 4-bit processors

edit
Intel D4004 (ceramic variant)
Intel P4004 (plastic variant)

Intel 4004

edit

First commercially available microprocessor (single-chip IC processor)

MCS-4 family:

  • 4004 – CPU
  • 4001 – 256 byte ROM & 4-bit Port
  • 4002 – 320 bit RAM & 4-bit Port
  • 4003 – 10-bit Shift Register
  • 4008 – Memory+I/O Interface
  • 4009 – Memory+I/O Interface
  • 4211 – General Purpose Byte I/O Port
  • 4265 – Programmable General Purpose I/O Device
  • 4269 – Programmable Keyboard Display Device
  • 4289 – Standard Memory Interface for MCS-4/40
  • 4801 – 5.185 MHz Clock Generator Crystal for 4004/4201A or 4040/4201A
Intel C4040

Intel 4040

edit
  • Introduced in 1974 by Intel
  • Clock speed was 740 kHz (same as the 4004 microprocessor)
  • 3,000 transistors
  • Interrupt features were available
  • Programmable memory size: 8 KB (8192 B)
  • 640 bytes of data memory
  • 24-pin DIP

The 8-bit processors

edit
Intel D8008

8008

edit
  • Introduced April 1, 1972
  • Clock rate 500 kHz (8008-1: 800 kHz)
  • 0.05 MIPS
  • Bus width: 8 bits (triple-multiplexed address/data due to limited pins)
  • Enhancement load PMOS logic
  • 3,500 transistors at 10 μm
  • Addressable memory 16 KB
  • Typical in early 8-bit microcomputers, dumb terminals, general calculators, bottling machines
  • Developed in tandem with 4004
  • Originally intended for use in the Datapoint 2200 microcomputer
  • Key volume deployment in Texas Instruments 742 microcomputer in >3,000 Ford dealerships
Intel D8080

8080

edit
  • Introduced April 1, 1974
  • Clock rate 2 MHz (very rare 8080B: 3 MHz)
  • 0.29 MIPS[26]
  • Data bus width: 8 bits, address bus: 16 bits
  • Enhancement load NMOS logic
  • 4,500 transistors at 6 μm
  • Assembly language downward compatible with 8008
  • Addressable memory 64 KB (64 × 1024 B)
  • Up to 10× the performance of the 8008
  • Used in the Altair 8800, traffic light controller, cruise missile
  • Required two support chips versus 20 for the 8008
Intel D8085A
Intel P8085 (plastic variant)

8085

edit

Microcontrollers

edit

They are ICs with CPU, RAM, ROM (or PROM or EPROM), I/O Ports, Timers & Interrupts

Intel P8048H

Intel 8048

edit

MCS-48 family:

  • 8020 – Single-Component 8-bit Microcontroller, 1 KB ROM, 64 Byte RAM, 13 I/O ports
  • 8021 – Single-Component 8-bit Microcontroller, 1 KB ROM, 64 Byte RAM, 21 I/O ports
  • 8022 – Single-Component 8-bit Microcontroller, 2 KB ROM, 64 Byte RAM with on-chip A/D Converter
  • 8035 – 8-bit Microcontroller, 64 Byte RAM
  • 8039 – 8-bit Microcontroller, 128 Byte RAM
  • 8040 – 8-bit Microcontroller, 256 Byte RAM
  • 8048 – Single-Component 8-bit Microcontroller, 1 KB ROM, 64 byte RAM, 27 I/O ports, 0.73 MIPS @ 11 MHz
  • 8049 – Single-Component 8-bit Microcontroller, 2 KB ROM, 128 byte RAM, 27 I/O ports,
  • 8050 – Single-Component 8-bit Microcontroller, 4 KB ROM, 256 byte RAM, 27 I/O ports,
  • 8748 – Single-Component 8-bit Microcontroller, 1 KB EPROM, 64 byte RAM, 27 I/O ports,
  • 8749 – Single-Component 8-bit Microcontroller, 2 KB EPROM, 128 byte RAM, 27 I/O ports,
  • 87P50 – 8-bit Microcontroller, ext. ROM socket (2758/2716/2732), 256 byte RAM, 27 I/O ports
  • 8648 – Single-Component 8-bit Microcontroller, 1 KB OTP EPROM, 64 byte RAM, 27 I/O ports
  • 8041 – Universal Peripheral Interface 8-bit Slave Microcontroller, 1 KB ROM, 64 byte RAM
  • 8041AH – Universal Peripheral Interface 8-bit Slave Microcontroller, 1 KB ROM, 128 byte RAM
  • 8641 – Universal Peripheral Interface 8-bit Slave Microcontroller ?
  • 8741 – Universal Peripheral Interface 8-bit Slave Microcontroller, 1 KB EPROM, 64 byte RAM
  • 8741AH – Universal Peripheral Interface 8-bit Slave Microcontroller, 1 KB EPROM, 128 byte RAM
  • 8042 – Universal Peripheral Interface 8-bit Slave Microcontroller, 2 KB ROM, 256 byte RAM
  • 8742 – Universal Peripheral Interface 8-bit Slave Microcontroller, 2 KB EPROM, 128 byte RAM
  • 8742AH – Universal Peripheral Interface 8-bit Slave Microcontroller, 2 KB OTP EPROM, 256 byte RAM
Intel P8051

Intel 8051

edit

MCS-51 family:

  • 8031 – 8-bit Control-Oriented Microcontroller
  • 8032 – 8-bit Control-Oriented Microcontroller
  • 8044 – High Performance 8-bit Microcontroller
  • 8344 – High Performance 8-bit Microcontroller
  • 8744 – High Performance 8-bit Microcontroller
  • 8051 – 8-bit Control-Oriented Microcontroller
  • 8052 – 8-bit Control-Oriented Microcontroller
  • 8054 – 8-bit Control-Oriented Microcontroller
  • 8058 – 8-bit Control-Oriented Microcontroller
  • 8351 – 8-bit Control-Oriented Microcontroller
  • 8352 – 8-bit Control-Oriented Microcontroller
  • 8354 – 8-bit Control-Oriented Microcontroller
  • 8358 – 8-bit Control-Oriented Microcontroller
  • 8751 – 8-bit Control-Oriented Microcontroller
  • 8752 – 8-bit Control-Oriented Microcontroller
  • 8754 – 8-bit Control-Oriented Microcontroller
  • 8758 – 8-bit Control-Oriented Microcontroller

Intel 80151

edit

MCS-151 family:

  • 80151 – High Performance 8-bit Control-Oriented Microcontroller
  • 83151 – High Performance 8-bit Control-Oriented Microcontroller
  • 87151 – High Performance 8-bit Control-Oriented Microcontroller
  • 80152 – High Performance 8-bit Control-Oriented Microcontroller
  • 83152 – High Performance 8-bit Control-Oriented Microcontroller

Intel 80251

edit

MCS-251 family:

  • 80251 – 8/16/32-bit Microcontroller
  • 80252 – 8/16/32-bit Microcontroller
  • 80452 – 8/16/32-bit Microcontroller
  • 83251 – 8/16/32-bit Microcontroller
  • 87251 – 8/16/32-bit Microcontroller
  • 87253 – 8/16/32-bit Microcontroller

MCS-96 family

edit
  • 8061 – 16-bit Microcontroller (parent of MCS-96 family ROMless With A/D, most sold to Ford)
  • 8094 – 16-bit Microcontroller (48-Pin ROMLess Without A/D)
  • 8095 – 16-bit Microcontroller (48-Pin ROMLess With A/D)
  • 8096 – 16-bit Microcontroller (68-Pin ROMLess Without A/D)
  • 8097 – 16-bit Microcontroller (68-Pin ROMLess With A/D)
  • 8394 – 16-bit Microcontroller (48-Pin With ROM Without A/D)
  • 8395 – 16-bit Microcontroller (48-Pin With ROM With A/D)
  • 8396 – 16-bit Microcontroller (68-Pin With ROM Without A/D)
  • 8397 – 16-bit Microcontroller (68-Pin With ROM With A/D)
  • 8794 – 16-bit Microcontroller (48-Pin With EROM Without A/D)
  • 8795 – 16-bit Microcontroller (48-Pin With EROM With A/D)
  • 8796 – 16-bit Microcontroller (68-Pin With EROM Without A/D)
  • 8797 – 16-bit Microcontroller (68-Pin With EROM With A/D)
  • 8098 – 16-bit Microcontroller
  • 8398 – 16-bit Microcontroller
  • 8798 – 16-bit Microcontroller
  • 80196 – 16-bit Microcontroller
  • 83196 – 16-bit Microcontroller
  • 87196 – 16-bit Microcontroller
  • 80296 – 16-bit Microcontroller

The bit-slice processor

edit

3000 family

edit
Intel D3001
Intel D3002
Intel C3003

Introduced in the third quarter of 1974, these bit-slicing components used bipolar Schottky transistors. Each component implemented two bits of a processor function; packages could be interconnected to build a processor with any desired word length.

Members of the 3000 family:

  • 3001 – Microcontrol Unit
  • 3002 – 2-bit Arithmetic Logic Unit slice[28]
  • 3003 – Look-ahead Carry Generator
  • 3205 – High-performance 1 of 8 Binary Decoder
  • 3207 – Quad Bipolar-to-MOS Level Shifter and Driver
  • 3208 – Hex Sense Amp and Latch for MOS Memories
  • 3210 – TTL-to-MOS Level Shifter and High Voltage Clock Driver
  • 3211 – ECL-to-MOS Level Shifter and High Voltage Clock Driver
  • 3212 – Multimode Latch Buffer
  • 3214 – Interrupt Control Unit
  • 3216 – Parallel, Inverting Bi-Directional Bus Driver
  • 3222 – Refresh Controller for 4K (4096 B) NMOS DRAMs
  • 3226 – Parallel, Inverting Bi-Directional Bus Driver
  • 3232 – Address Multiplexer and Refresh Counter for 4K DRAMs
  • 3242 – Address Multiplexer and Refresh Counter for 16K (16 × 1024 B) DRAMs
  • 3245 – Quad Bipolar TTL-to-MOS Level Shifter and Driver for 4K
  • 3246 – Quad Bipolar ECL-to-MOS Level Shifter and Driver for 4K
  • 3404 – High-performance 6-bit Latch
  • 3408 – Hex Sense Amp and Latch for MOS Memories
  • 3505 – Next generation processor

Bus width 2n bits data/address (depending on number n of slices used)

The 16-bit processors: MCS-86 family

edit
Intel D8086

8086

edit
  • Introduced June 8, 1978
  • Clock rates:
    • 5 MHz, 0.33 MIPS[27]
    • 8 MHz, 0.66 MIPS
    • 10 MHz, 0.75 MIPS
  • The memory is divided into odd and even banks. It accesses both banks concurrently to read 16 bits of data in one memory cycle
  • Data bus width: 16 bits, address bus: 20 bits, multiplexed
  • 29,000 transistors at 3 μm
  • Addressable memory: 1 megabyte (10242 B)
  • Up to 10× the performance of 8080
  • First used in the Compaq Deskpro IBM PC-compatible computers. Later used in portable computing, and in the IBM PS/2 Model 25 and Model 30. Also used in the AT&T PC6300 / Olivetti M24, a popular IBM PC-compatible (predating the IBM PS/2 line) and the WANG PC.
  • Used segment registers to access more than 64 KB of data at once.
  • The first x86 CPU
  • Later renamed the iAPX 86[29]
Intel D8088

8088

edit
  • Introduced June 1, 1979
  • Clock rates:
    • 4.77 MHz, 0.33 MIPS
    • 8 MHz, 0.66 MIPS[27]
  • 16-bit internal architecture
  • External data bus width: 8 bits, address bus: 20 bits, lower 8 bits multiplexed
  • 29,000 transistors at 3 μm
  • Addressable memory: 1 megabyte
  • Identical to 8086 except for its 8-bit external bus (hence an 8 instead of a 6 at the end); identical Execution Unit (EU), different Bus Interface Unit (BIU)[29]
  • Used in IBM PC and PC-XT and compatibles
  • Later renamed the iAPX 88[29]
Intel C80186 6 MHz

80186

edit
  • Introduced 1982
  • Clock rates
    • 6 MHz, > 1 MIPS
  • 55,000 transistors
  • Included two timers, a DMA controller, and an interrupt controller on the chip in addition to the processor (these were at fixed addresses which differed from the IBM PC, although it was used by several PC compatible vendors such as Australian company Cleveland)
  • Added a few opcodes and exceptions to the 8086 design, otherwise identical instruction set to 8086 and 8088
    • BOUND, ENTER, LEAVE
    • INS, OUTS
    • IMUL imm, PUSH imm, PUSHA, POPA
    • RCL/RCR/ROL/ROR/SHL/SHR/SAL/SAR reg, imm
  • Address calculation and shift operations are faster than 8086
  • Used mostly in embedded applications – controllers, point-of-sale systems, terminals, and the like
  • Used in several non-PC compatible computers including RM Nimbus, Tandy 2000, and CP/M 86 Televideo PM16 server
  • Later renamed to iAPX 186

80188

edit
  • A version of the 80186 with an 8-bit external data bus
  • Later renamed the iAPX 188
Intel C80286 6 MHz

80286

edit
  • Introduced February 1, 1982
  • Clock rates:
    • 6 MHz, 0.9 MIPS
    • 8 MHz, 10 MHz, 1.5 MIPS
    • 12.5 MHz, 2.66 MIPS
    • 16 MHz, 20 MHz and 25 MHz available.
  • Data bus width: 16 bits, address bus: 24 bits
  • Included memory protection hardware to support multitasking operating systems with per-process address space.
  • 134,000 transistors at 1.5 μm
  • Addressable memory 16 MB
  • Added protected-mode features to 8086 with essentially the same instruction set
  • 3–6× the performance of the 8086
  • Widely used in IBM PC AT and AT clones contemporary to it

32-bit processors: the non-x86 microprocessors

edit

iAPX 432

edit
  • Introduced January 1, 1981 as Intel's first 32-bit microprocessor
  • Multi-chip CPU
  • Object/capability architecture
  • Microcoded operating system primitives
  • One terabyte virtual address space
  • Hardware support for fault tolerance
  • Two-chip General Data Processor (GDP), consists of 43201 and 43202
  • 43203 Interface Processor (IP) interfaces to I/O subsystem
  • 43204 Bus Interface Unit (BIU) simplifies building multiprocessor systems
  • 43205 Memory Control Unit (MCU)
  • Architecture and execution unit internal data base paths: 32 bits
  • Clock rates:
    • 5 MHz
    • 7 MHz
    • 8 MHz

i960 a.k.a. 80960

edit
  • Introduced April 5, 1988
  • RISC-like 32-bit architecture
  • Predominantly used in embedded systems
  • Evolved from the capability processor developed for the BiiN joint venture with Siemens
  • Many variants identified by two-letter suffixes

i860 a.k.a. 80860

edit

XScale

edit
  • Introduced August 23, 2000
  • 32-bit RISC microprocessor based on the ARM architecture
  • Many variants, such as the PXA2xx applications processors, IOP3xx I/O processors and IXP2xxx and IXP4xx network processors

32-bit processors: the 80386 range

edit
Intel 80386DX
Intel 80386DX with Intel 387 math processor

80386DX

edit
  • Introduced October 17, 1985
  • Clock rates:
    • 16 MHz, 5 MIPS
    • 20 MHz, 6 to 7 MIPS, introduced February 16, 1987
    • 25 MHz, 7.5 MIPS, introduced April 4, 1988
    • 33 MHz, 9.9 MIPS (9.4 SPECint92 on Compaq/i 16 KB L2), introduced April 10, 1989
  • Data bus width: 32 bits, address bus: 32 bits
  • 275,000 transistors at 1 μm
  • Addressable memory 4 GB (4 × 10243 B = 232)
  • Virtual memory 64 TB (64 × 10244 B = 246)[30][31]
  • First x86 chip to handle 32-bit data sets
  • Reworked and expanded memory protection support including paged virtual memory and virtual-86 mode, features required at the time by Xenix and Unix. This memory capability spurred the development and availability of OS/2 and is a fundamental requirement for modern operating systems like Linux, Windows, and macOS
  • First used by Compaq in the Deskpro 386. Used in desktop computing
  • Unlike the DX naming convention of the 486 chips, it had no math co-processor
  • Later renamed Intel386 DX

80386SX

edit
  • Introduced June 16, 1988
  • Clock rates:
    • 16 MHz, 2.5 MIPS
    • 20 MHz, 3.1 MIPS, introduced January 25, 1989
    • 25 MHz, 3.9 MIPS, introduced January 25, 1989
    • 33 MHz, 5.1 MIPS, introduced October 26, 1992
  • 32-bit internal architecture
  • External data bus width: 16 bits
  • External address bus width: 24 bits
  • 275,000 transistors at 1 μm
  • Addressable memory 16 MB
  • Virtual memory 64 TB[30]
  • Narrower buses enable low-cost 32-bit processing
  • Used in entry-level desktop and portable computing
  • No math co-processor
  • No commercial software used protected mode or virtual storage for many years
  • Later renamed Intel386 SX

80376

edit
The Intel i376 is an embedded version of the i386SX.
  • Introduced January 16, 1989; discontinued June 15, 2001
  • Variant of 386SX intended for embedded systems
  • No "real mode", starts up directly in "protected mode"
  • Replaced by much more successful 80386EX from 1994

80386SL

edit
  • Introduced October 15, 1990
  • Clock rates:
    • 20 MHz, 4.21 MIPS
    • 25 MHz, 5.3 MIPS, introduced September 30, 1991
  • 32-bit internal architecture
  • External bus width: 16 bits
  • 855,000 transistors at 1 μm
  • Addressable memory 4 GB
  • Virtual memory 64 TB[30]
  • First chip specifically made for portable computers because of low power consumption of chip
  • Highly integrated, includes cache, bus, and memory controllers
Intel 80386EX

80386EX

edit
  • Introduced August 1994
  • Variant of 80386SX intended for embedded systems
  • Static core (i.e. may run as slowly (and thus, power efficiently) as desired) down to full halt
  • On-chip peripherals:
    • Clock and power management
    • Timers/counters
    • Watchdog timer
    • Serial I/O units (sync and async) and parallel I/O
    • DMA
    • RAM refresh
    • JTAG test logic
  • Significantly more successful than the 80376
  • Used aboard several orbiting satellites and microsatellites
  • Used in NASA's FlightLinux project

32-bit processors: the 80486 range

edit
Intel 80486DX 33 MHz

80486DX

edit
  • Introduced April 10, 1989
  • Clock rates:
    • 25 MHz, 20 MIPS (16.8 SPECint92, 7.40 SPECfp92)
    • 33 MHz, 27 MIPS (22.4 SPECint92 on Micronics M4P 128 KB L2), introduced May 7, 1990
    • 50 MHz, 41 MIPS (33.4 SPECint92, 14.5 SPECfp92 on Compaq/50L 256 KB L2), introduced June 24, 1991
  • Bus width: 32 bits
  • 1.2 million transistors at 1 μm; the 50 MHz was at 0.8 μm
  • Addressable memory 4 GB
  • Virtual memory 64 TB[30]
  • Level 1 cache of 8 KB on chip
  • Math coprocessor on chip
  • 50× performance of the 8088
  • Officially named Intel486 DX
  • Used in desktop computing and servers
  • Family 4 model 1
Intel 80486SX 33 MHz

80486SX

edit
  • Introduced April 22, 1991
  • Clock rates:
    • 16 MHz, 13 MIPS
    • 20 MHz, 16.5 MIPS, introduced September 16, 1991
    • 25 MHz, 20 MIPS (12 SPECint92), introduced September 16, 1991
    • 33 MHz, 27 MIPS (15.86 SPECint92), introduced September 21, 1992
  • Bus width: 32 bits
  • 1.185 million transistors at 1 μm and 900,000 at 0.8 μm
  • Addressable memory 4 GB
  • Virtual memory 64 TB[30]
  • Identical in design to 486DX but without a math coprocessor. The first version was an 80486DX with disabled math coprocessor in the chip and different pin configuration. If the user needed math coprocessor capabilities, they must add 487SX which was actually a 486DX with different pin configuration to prevent the user from installing a 486DX instead of 487SX, so with this configuration 486SX+487SX you had 2 identical CPU's with only 1 effectively turned on
  • Officially named Intel486 SX
  • Used in low-cost entry to 486 CPU desktop computing, as well as extensively in low cost mobile computing
  • Upgradable with the Intel OverDrive processor
  • Family 4 model 2
Intel 80486DX2 66 MHz

80486DX2

edit
  • Introduced March 3, 1992
  • Runs at twice the speed of the external bus (FSB)
  • Socket 3
  • Clock rates:
    • 40 MHz
    • 50 MHz, 41 MIPS
    • 66 MHz, 54 MIPS
  • Officially named Intel486 DX2
  • Family 4 model 3
Intel 80486SL

80486SL

edit
  • Introduced November 9, 1992
  • Clock rates:
    • 20 MHz, 15.4 MIPS
    • 25 MHz, 19 MIPS
    • 33 MHz, 25 MIPS
  • Bus width: 32 bits
  • 1.4 million transistors at 0.8 μm
  • Addressable memory 4 GB
  • Virtual memory 64 TB
  • Officially named Intel486 SL
  • Used in notebook computers
  • Family 4 model 4
Intel 80486DX4 100 MHz

80486DX4

edit
  • Introduced March 7, 1994
  • Clock rates:
    • 75 MHz, 53 MIPS (41.3 SPECint92, 20.1 SPECfp92 on Micronics M4P 256 KB L2)
    • 100 MHz, 70.7 MIPS (54.59 SPECint92, 26.91 SPECfp92 on Micronics M4P 256 KB L2)
  • 1.6 million transistors at 0.6 μm
  • Bus width: 32 bits
  • Addressable memory 4 GB
  • Virtual memory 64 TB
  • Socket 3 168-pin PGA Package, or 208 sq. ftP package
  • Officially named Intel486 DX4
  • Used in high performance entry-level desktops and value notebooks
  • Family 4 model 8

32-bit processors: P5 microarchitecture

edit
Intel Pentium P5 (A80501) 60 MHz, without GoldCap
Intel Pentium P5 (A80501) 66 MHz, with GoldCap

Original Pentium

edit
  • Introduced March 22, 1993
  • Bus width: 64 bits
  • System bus clock rate 60 or 66 MHz
  • Address bus: 32 bits
  • Addressable memory 4 GB
  • Virtual memory 64 TB
  • Superscalar architecture
  • Runs on 3.3 volts (except the very first generation "P5")
  • Used in desktops
  • 8 KB of instruction cache
  • 8 KB of data cache
  • P5 – 0.8 μm process technology
    • Introduced March 22, 1993
    • 3.1 million transistors
    • The only Pentium to run on 5 Volts
    • Socket 4 273 pin PGA Package
    • Package dimensions 2.16 in × 2.16 in
    • Family 5 model 1
    • Variants
      • 60 MHz, 100 MIPS (70.4 SPECint92, 55.1 SPECfp92 on Xpress 256 KB L2)
      • 66 MHz, 112 MIPS (77.9 SPECint92, 63.6 SPECfp92 on Xpress 256 KB L2)
  • P54 – 0.6 μm process technology
    • Socket 5 296/320-pin PGA package
    • 3.2 million transistors
    • Variants
      • 75 MHz, 126.5 MIPS (2.31 SPECint95, 2.02 SPECfp95 on Gateway P5 256K L2)
        • Introduced October 10, 1994
      • 90, 100 MHz, 149.8 and 166.3 MIPS respectively (2.74 SPECint95, 2.39 SPECfp95 on Gateway P5 256K L2 and 3.30 SPECint95, 2.59 SPECfp95 on Xpress 1ML2 respectively)
        • Introduced March 7, 1994
  • P54CQS – 0.35 μm process technology
    • Socket 5 296/320 pin PGA package
    • 3.2 million transistors
    • Variants
      • 120 MHz, 203 MIPS (3.72 SPECint95, 2.81 SPECfp95 on Xpress 1 MB L2)
        • Introduced March 27, 1995
  • Intel Pentium P54 133 MHz
    P54CS – 0.35 μm process technology
    • 3.3 million transistors
    • 90 mm2 die size
    • Family 5 model 2
    • Variants
    • Socket 5 296/320-pin PGA package
      • 133 MHz, 218.9 MIPS (4.14 SPECint95, 3.12 SPECfp95 on Xpress 1 MB L2)
        • Introduced June 12, 1995
      • 150, 166 MHz, 230 and 247 MIPS respectively
        • Introduced January 4, 1996
    • Socket 7 296/321-pin PGA package
      • 200 MHz, 270 MIPS (5.47 SPECint95, 3.68 SPECfp95)
        • Introduced June 10, 1996
Intel Pentium P55C 166 MHz

Pentium with MMX Technology

edit
  • P55C – 0.35 μm process technology
    • Introduced January 8, 1997
    • Intel MMX (instruction set) support
    • Socket 7 296/321 pin PGA (pin grid array) package
    • 16 KB L1 instruction cache
    • 16 KB data cache
    • 4.5 million transistors
    • System bus clock rate 66 MHz
    • Basic P55C is family 5 model 4, mobile are family 5 model 7 and 8
    • Variants
      • 166, 200 MHz introduced January 8, 1997
      • 233 MHz introduced June 2, 1997
      • 133 MHz (Mobile)
      • 166, 266 MHz (Mobile) introduced January 12, 1998
      • 200, 233 MHz (Mobile) introduced September 8, 1997
      • 300 MHz (Mobile) introduced January 7, 1999

32-bit processors: P6/Pentium M microarchitecture

edit
Intel Pentium Pro 200 MHz

Pentium Pro

edit
  • Introduced November 1, 1995
  • Multichip Module (2 die)
  • Precursor to Pentium II and III
  • Primarily used in server systems
  • Socket 8 processor package (387 pins; Dual SPGA)
  • 5.5 million transistors
  • Family 6 model 1
  • 0.6 μm process technology
    • 16 KB L1 cache
    • 256 KB integrated L2 cache
    • 60 MHz system bus clock rate
    • Variants
      • 150 MHz
  • 0.35 μm process technology, (two die, a 0.35 μm CPU with 0.6 μm L2 cache)
    • 5.5 million transistors
    • 512 KB or 256 KB integrated L2 cache
    • 60 or 66 MHz system bus clock rate
    • Variants
      • 150 MHz (60 MHz bus clock rate, 256 KB 0.6 μm cache) introduced November 1, 1995
      • 166 MHz (66 MHz bus clock rate, 512 KB 0.35 μm cache) introduced November 1, 1995
      • 180 MHz (60 MHz bus clock rate, 256 KB 0.6 μm cache) introduced November 1, 1995
      • 200 MHz (66 MHz bus clock rate, 256 KB 0.6 μm cache) introduced November 1, 1995
      • 200 MHz (66 MHz bus clock rate, 512 KB 0.35 μm cache) introduced November 1, 1995
      • 200 MHz (66 MHz bus clock rate, 1 MB 0.35 μm cache) introduced August 18, 1997

Pentium II

edit
  • Introduced May 7, 1997
  • Pentium Pro with MMX and improved 16-bit performance
  • 242-pin Slot 1 (SEC) processor package
  • Voltage identification pins
  • 7.5 million transistors
  • 32 KB L1 cache
  • 512 KB 1⁄2 frequency external L2 cache
  • The Performance Enhanced mobile Pentium II (codenamed Dixon) had a full-speed 256 KB L2 cache
  • Klamath – 0.35 μm process technology (233, 266, 300 MHz)
    • 66 MHz system bus clock rate
    • Family 6 model 3
    • Variants
      • 233, 266, 300 MHz introduced May 7, 1997
  • Deschutes – 0.25 μm process technology (333, 350, 400, 450 MHz)
    • Introduced January 26, 1998
    • 66 MHz system bus clock rate (333 MHz variant), 100 MHz system bus clock rate for all subsequent models
    • Family 6 model 5
    • Variants
      • 333 MHz introduced January 26, 1998
      • 350, 400 MHz introduced April 15, 1998
      • 450 MHz introduced August 24, 1998
      • 233, 266 MHz (Mobile) introduced April 2, 1998
      • 333 MHz Pentium II Overdrive processor for Socket 8 Introduced August 10, 1998
      • 300 MHz (Mobile) introduced September 9, 1998
      • 333 MHz (Mobile) introduced January 25, 1999

Celeron (Pentium II–based)

edit
  • Covington – 0.25 μm process technology
    • Introduced April 15, 1998
    • 242-pin Slot 1 SEPP (Single Edge Processor Package)
    • 7.5 million transistors
    • 66 MHz system bus clock rate
    • Slot 1
    • 32 KB L1 cache
    • No L2 cache
    • Variants
      • 266 MHz introduced April 15, 1998
      • 300 MHz introduced June 9, 1998
  • Mendocino – 0.25 μm process technology
    • Introduced August 24, 1998
    • 242-pin Slot 1 SEPP (Single Edge Processor Package), Socket 370 PPGA package
    • 19 million transistors
    • 66 MHz system bus clock rate
    • Slot 1, Socket 370
    • 32 KB L1 cache
    • 128 KB integrated cache
    • Family 6 model 6
    • Variants
      • 300, 333 MHz introduced August 24, 1998
      • 366, 400 MHz introduced January 4, 1999
      • 433 MHz introduced March 22, 1999
      • 466 MHz
      • 500 MHz introduced August 2, 1999
      • 533 MHz introduced January 4, 2000
      • 266 MHz (Mobile)
      • 300 MHz (Mobile)
      • 333 MHz (Mobile) introduced April 5, 1999
      • 366 MHz (Mobile)
      • 400 MHz (Mobile)
      • 433 MHz (Mobile)
      • 450 MHz (Mobile) introduced February 14, 2000
      • 466 MHz (Mobile)
      • 500 MHz (Mobile) introduced February 14, 2000

Pentium II Xeon (chronological entry)

See also: § Pentium II Xeon and Pentium III Xeon
  • Introduced June 29, 1998

Pentium III

edit
  • Katmai – 0.25 μm process technology
    • Introduced February 26, 1999
    • Improved PII (i.e. P6-based core) now including Streaming SIMD Extensions (SSE)
    • 9.5 million transistors
    • 512 KB (512 × 1024 B) 1⁄2 bandwidth L2 External cache
    • 242-pin Slot 1 SECC2 (Single Edge Contact cartridge 2) processor package
    • System bus clock rate 100 MHz, 133 MHz (B-models)
    • Slot 1
    • Family 6 model 7
    • Variants
      • 450, 500 MHz introduced February 26, 1999
      • 550 MHz introduced May 17, 1999
      • 600 MHz introduced August 2, 1999
      • 533, 600 MHz introduced (133 MHz bus clock rate) September 27, 1999
  • Coppermine – 0.18 μm process technology
    • Introduced October 25, 1999
    • 28.1 million transistors
    • 256 KB (512 × 1024 B) Advanced Transfer L2 cache (integrated)
    • 242-pin Slot-1 SECC2 (Single Edge Contact cartridge 2) processor package, 370-pin FC-PGA (flip-chip pin grid array) package
    • System Bus clock rate 100 MHz (E-models), 133 MHz (EB models)
    • Slot 1, Socket 370
    • Family 6 model 8
    • Variants
      • 500 MHz (100 MHz bus clock rate)
      • 533 MHz
      • 550 MHz (100 MHz bus clock rate)
      • 600 MHz
      • 600 MHz (100 MHz bus clock rate)
      • 650 MHz (100 MHz bus clock rate) introduced October 25, 1999
      • 667 MHz introduced October 25, 1999
      • 700 MHz (100 MHz bus clock rate) introduced October 25, 1999
      • 733 MHz introduced October 25, 1999
      • 750, 800 MHz (100 MHz bus clock rate) introduced December 20, 1999
      • 850 MHz (100 MHz bus clock rate) introduced March 20, 2000
      • 866 MHz introduced March 20, 2000
      • 933 MHz introduced May 24, 2000
      • 1000 MHz introduced March 8, 2000 (not widely available at time of release)
      • 1100 MHz
      • 1133 MHz (first version recalled, later re-released)
      • 400, 450, 500 MHz (Mobile) introduced October 25, 1999
      • 600, 650 MHz (Mobile) introduced January 18, 2000
      • 700 MHz (Mobile) introduced April 24, 2000
      • 750 MHz (Mobile) introduced June 19, 2000
      • 800, 850 MHz (Mobile) introduced September 25, 2000
      • 900, 1000 MHz (Mobile) introduced March 19, 2001
  • Tualatin – 0.13 μm process technology
    • Introduced July 2001
    • 28.1 million transistors
    • 32 KB (32 × 1024 B) L1 cache
    • 256 KB or 512 KB Advanced Transfer L2 cache (integrated)
    • 370-pin FC-PGA2 (flip-chip pin grid array) package
    • 133 MHz system bus clock rate
    • Socket 370
    • Family 6 model 11
    • Variants
      • 1133 MHz (256 KB L2)
      • 1133 MHz (512 KB L2)
      • 1200 MHz
      • 1266 MHz (512 KB L2)
      • 1333 MHz
      • 1400 MHz (512 KB L2)

Pentium II Xeon and Pentium III Xeon

edit
  • PII Xeon
    • Variants
      • 400 MHz introduced June 29, 1998
      • 450 MHz (512 KB L2 cache) introduced October 6, 1998
      • 450 MHz (1 MB and 2 MB L2 cache) introduced January 5, 1999
  • PIII Xeon
    • Introduced October 25, 1999
    • 9.5 million transistors at 0.25 μm or 28 million at 0.18 μm
    • L2 cache is 256 KB, 1 MB, or 2 MB Advanced Transfer Cache (Integrated)
    • Processor Package Style is Single Edge Contact Cartridge (S.E.C.C.2) or SC330
    • System Bus clock rate 133 MHz (256 KB L2 cache) or 100 MHz (1–2 MB L2 cache)
    • System Bus width: 64 bits
    • Addressable memory: 64 GB
    • Used in two-way servers and workstations (256 KB L2) or 4- and 8-way servers (1–2 MB L2)
    • Family 6 model 10
    • Variants
      • 500 MHz (0.25 μm process) introduced March 17, 1999
      • 550 MHz (0.25 μm process) introduced August 23, 1999
      • 600 MHz (0.18 μm process, 256 KB L2 cache) introduced October 25, 1999
      • 667 MHz (0.18 μm process, 256 KB L2 cache) introduced October 25, 1999
      • 733 MHz (0.18 μm process, 256 KB L2 cache) introduced October 25, 1999
      • 800 MHz (0.18 μm process, 256 KB L2 cache) introduced January 12, 2000
      • 866 MHz (0.18 μm process, 256 KB L2 cache) introduced April 10, 2000
      • 933 MHz (0.18 μm process, 256 KB L2 cache)
      • 1000 MHz (0.18 μm process, 256 KB L2 cache) introduced August 22, 2000
      • 700 MHz (0.18 μm process, 1–2 MB L2 cache) introduced May 22, 2000

Celeron (Pentium III Coppermine-based)

edit
  • Coppermine-128, 0.18 μm process technology
    • Introduced March, 2000
    • Streaming SIMD Extensions (SSE)
    • Socket 370, FC-PGA processor package
    • 28.1 million transistors
    • 66 MHz system bus clock rate, 100 MHz system bus clock rate from January 3, 2001
    • 32 KB L1 cache
    • 128 KB Advanced Transfer L2 cache
    • Family 6 model 8
    • Variants
      • 533 MHz
      • 566 MHz
      • 600 MHz
      • 633, 667, 700 MHz introduced June 26, 2000
      • 733, 766 MHz introduced November 13, 2000
      • 800 MHz introduced January 3, 2001
      • 850 MHz introduced April 9, 2001
      • 900 MHz introduced July 2, 2001
      • 950, 1000, 1100 MHz introduced August 31, 2001
      • 550 MHz (Mobile)
      • 600, 650 MHz (Mobile) introduced June 19, 2000
      • 700 MHz (Mobile) introduced September 25, 2000
      • 750 MHz (Mobile) introduced March 19, 2001
      • 800 MHz (Mobile)
      • 850 MHz (Mobile) introduced July 2, 2001
      • 600 MHz (LV Mobile)
      • 500 MHz (ULV Mobile) introduced January 30, 2001
      • 600 MHz (ULV Mobile)

XScale (chronological entry – non-x86 architecture)

See also: § XScale
  • Introduced August 23, 2000

Pentium 4 (not 4EE, 4E, 4F), Itanium, P4-based Xeon, Itanium 2 (chronological entries)

See main entries
  • Introduced April 2000 – July 2002

Pentium III Tualatin-based

edit
  • Tualatin – 0.13 μm process technology
    • 32 KB L1 cache
    • 512 KB Advanced Transfer L2 cache
    • 133 MHz system bus clock rate
    • Socket 370
    • Variants
      • 1.0 GHz
      • 1.13 GHz
      • 1.26 GHz
      • 1.4 GHz

Celeron (Pentium III Tualatin-based)

edit
  • Tualatin Celeron – 0.13 μm process technology
    • 32 KB L1 cache
    • 256 KB Advanced Transfer L2 cache
    • 100 MHz system bus clock rate
    • Socket 370
    • Family 6 model 11
    • Variants
      • 1.0 GHz
      • 1.1 GHz
      • 1.2 GHz
      • 1.3 GHz
      • 1.4 GHz

Pentium M

edit
  • Banias 0.13 μm process technology
    • Introduced March 2003
    • 64 KB L1 cache
    • 1 MB L2 cache (integrated)
    • Based on Pentium III core, with SSE2 SIMD instructions and deeper pipeline
    • 77 million transistors
    • Micro-FCPGA, Micro-FCBGA processor package
    • Heart of the Intel mobile Centrino system
    • 400 MHz NetBurst-style system bus
    • Family 6 model 9
    • Variants
      • 900 MHz (ultra-low voltage)
      • 1.0 GHz (ultra-low voltage)
      • 1.1 GHz (low voltage)
      • 1.2 GHz (low voltage)
      • 1.3 GHz
      • 1.4 GHz
      • 1.5 GHz
      • 1.6 GHz
      • 1.7 GHz
  • Dothan 0.09 μm (90 nm) process technology
    • Introduced May 2004
    • 2 MB L2 cache
    • 140 million transistors
    • Revised data prefetch unit
    • 400 MHz NetBurst-style system bus
    • 21 W TDP
    • Family 6 model 13
    • Variants
      • 1.00 GHz (Pentium M 723) (ultra-low voltage, 5 W TDP)
      • 1.10 GHz (Pentium M 733) (ultra-low voltage, 5 W TDP)
      • 1.20 GHz (Pentium M 753) (ultra-low voltage, 5 W TDP)
      • 1.30 GHz (Pentium M 718) (low voltage, 10 W TDP)
      • 1.40 GHz (Pentium M 738) (low voltage, 10 W TDP)
      • 1.50 GHz (Pentium M 758) (low voltage, 10 W TDP)
      • 1.60 GHz (Pentium M 778) (low voltage, 10 W TDP)
      • 1.40 GHz (Pentium M 710)
      • 1.50 GHz (Pentium M 715)
      • 1.60 GHz (Pentium M 725)
      • 1.70 GHz (Pentium M 735)
      • 1.80 GHz (Pentium M 745)
      • 2.00 GHz (Pentium M 755)
      • 2.10 GHz (Pentium M 765)
  • Dothan 533 0.09 μm (90 nm) process technology
    • Introduced Q1 2005
    • Same as Dothan except with a 533 MHz NetBurst-style system bus and 27 W TDP
    • Variants
      • 1.60 GHz (Pentium M 730)
      • 1.73 GHz (Pentium M 740)
      • 1.86 GHz (Pentium M 750)
      • 2.00 GHz (Pentium M 760)
      • 2.13 GHz (Pentium M 770)
      • 2.26 GHz (Pentium M 780)
  • Stealey 0.09 μm (90 nm) process technology
    • Introduced Q2 2007
    • 512 KB L2, 3 W TDP
    • Variants
      • 600 MHz (A100)
      • 800 MHz (A110)

Celeron M

edit
  • Banias-512 0.13 μm process technology
    • Introduced March 2003
    • 64 KB L1 cache
    • 512 KB L2 cache (integrated)
    • SSE2 SIMD instructions
    • No SpeedStep technology, is not part of the 'Centrino' package
    • Family 6 model 9
    • Variants
      • 310, 1.20 GHz
      • 320, 1.30 GHz
      • 330, 1.40 GHz
      • 340, 1.50 GHz
  • Dothan-1024 90 nm process technology
    • 64 KB L1 cache
    • 1 MB L2 cache (integrated)
    • SSE2 SIMD instructions
    • No SpeedStep technology, is not part of the 'Centrino' package
    • Variants
      • 350, 1.30 GHz
      • 350J, 1.30 GHz, with Execute Disable bit
      • 360, 1.40 GHz
      • 360J, 1.40 GHz, with Execute Disable bit
      • 370, 1.50 GHz, with Execute Disable bit
        • Family 6, Model 13, Stepping 8[32]
      • 380, 1.60 GHz, with Execute Disable bit
      • 390, 1.70 GHz, with Execute Disable bit
  • Yonah-1024 65 nm process technology
    • 64 KB L1 cache
    • 1 MB L2 cache (integrated)
    • SSE3 SIMD instructions, 533 MHz front-side bus, execute-disable bit
    • No SpeedStep technology, is not part of the 'Centrino' package
    • Variants
      • 410, 1.46 GHz
      • 420, 1.60 GHz,
      • 423, 1.06 GHz (ultra-low voltage)
      • 430, 1.73 GHz
      • 440, 1.86 GHz
      • 443, 1.20 GHz (ultra-low voltage)
      • 450, 2.00 GHz

Intel Core

edit
  • Yonah 0.065 μm (65 nm) process technology
    • Introduced January 2006
    • 533/667 MHz front-side bus
    • 2 MB (Shared on Duo) L2 cache
    • SSE3 SIMD instructions
    • 31W TDP (T versions)
    • Family 6, Model 14
    • Variants:
      • Intel Core Duo T2700 2.33 GHz
      • Intel Core Duo T2600 2.16 GHz
      • Intel Core Duo T2500 2 GHz
      • Intel Core Duo T2450 2 GHz
      • Intel Core Duo T2400 1.83 GHz
      • Intel Core Duo T2300 1.66 GHz
      • Intel Core Duo T2050 1.6 GHz
      • Intel Core Duo T2300e 1.66 GHz
      • Intel Core Duo T2080 1.73 GHz
      • Intel Core Duo L2500 1.83 GHz (low voltage, 15 W TDP)
      • Intel Core Duo L2400 1.66 GHz (low voltage, 15 W TDP)
      • Intel Core Duo L2300 1.5 GHz (low voltage, 15 W TDP)
      • Intel Core Duo U2500 1.2 GHz (ultra-low voltage, 9 W TDP)
      • Intel Core Solo T1350 1.86 GHz (533 FSB)
      • Intel Core Solo T1300 1.66 GHz
      • Intel Core Solo T1200 1.5 GHz[33]

Dual-Core Xeon LV

edit
  • Sossaman 0.065 μm (65 nm) process technology
    • Introduced March 2006
    • Based on Yonah core, with SSE3 SIMD instructions
    • 667 MHz frontside bus
    • 2 MB shared L2 cache
    • Variants
      • 2.0 GHz

32-bit processors: NetBurst microarchitecture

edit

Pentium 4

edit
  • 0.18 μm process technology (1.40 and 1.50 GHz)
    • Introduced November 20, 2000
    • L2 cache was 256 KB Advanced Transfer cache (integrated)
    • Processor package Style was PGA423, PGA478
    • System bus clock rate 400 MHz
    • SSE2 SIMD Extensions
    • 42 million transistors
    • Used in desktops and entry-level workstations
  • 0.18 μm process technology (1.7 GHz)
    • Introduced April 23, 2001
    • See the 1.4 and 1.5 chips for details
  • 0.18 μm process technology (1.6 and 1.8 GHz)
    • Introduced July 2, 2001
    • See 1.4 and 1.5 chips for details
    • Core voltage is 1.15 volts in Maximum Performance Mode; 1.05 volts in battery optimized mode
    • Power <1 watt in battery optimized mode
    • Used in full-size and then light mobile PCs
  • 0.18 μm process technology Willamette (1.9 and 2.0 GHz)
    • Introduced August 27, 2001
    • See 1.4 and 1.5 chips for details
  • Family 15 model 1
  • Pentium 4 (2 GHz, 2.20 GHz)
    • Introduced January 7, 2002
  • Pentium 4 (2.4 GHz)
    • Introduced April 2, 2002
  • 0.13 μm process technology Northwood A (1.7, 1.8, 1.9, 2, 2.2, 2.4, 2.5, 2.6, 2.8 (OEM), 3.0 (OEM) GHz)
    • Improved branch prediction and other microcodes tweaks
    • 512 KB integrated L2 cache
    • 55 million transistors
    • 400 MHz system bus
  • Family 15 model 2
  • 0.13 μm process technology Northwood B (2.26, 2.4, 2.53, 2.66, 2.8, 3.06 GHz)
  • 0.13 μm process technology Northwood C (2.4, 2.6, 2.8, 3.0, 3.2, 3.4 GHz)
    • 800 MHz system bus (all versions include Hyper-Threading)
    • 6500 to 10,000 MIPS

Itanium (chronological entry – new non-x86 architecture)

See also: § Itanium
  • Introduced 2001

Xeon (32-bit NetBurst)

edit
  • Official designation now Xeon; i.e. not "Pentium 4 Xeon"
  • Xeon 1.4, 1.5, 1.7 GHz
    • Introduced May 21, 2001
    • L2 cache was 256 KB Advanced Transfer cache (integrated)
    • Processor package Organic Land Grid Array 603 (OLGA 603)
    • System bus clock rate 400 MHz
    • SSE2 SIMD Extensions
    • Used in high-performance and mid-range dual processor enabled workstations
  • Xeon 2.0 GHz and up to 3.6 GHz
    • Introduced September 25, 2001

Itanium 2 (chronological entry – new non-x86 architecture)

Mobile Pentium 4-M

edit
  • 0.13 μm process technology
  • 55 million transistors
  • 512 KB L2 cache
  • BUS a 400 MHz
  • Supports up to 1 GB of DDR 266 MHz memory
  • Supports ACPI 2.0 and APM 1.2 System Power Management
  • 1.3–1.2 V (SpeedStep)
  • Power: 1.2 GHz 20.8 W, 1.6 GHz 30 W, 2.6 GHz 35 W
  • Sleep power 5 W (1.2 V)
  • Deeper sleep power 2.9 W (1.0 V)
    • 1.40 GHz – 23 April 2002
    • 1.50 GHz – 23 April 2002
    • 1.60 GHz – 4 March 2002
    • 1.70 GHz – 4 March 2002
    • 1.80 GHz – 23 April 2002
    • 1.90 GHz – 24 June 2002
    • 2.00 GHz – 24 June 2002
    • 2.20 GHz – 16 September 2002
    • 2.40 GHz – 14 January 2003
    • 2.50 GHz – 16 April 2003
    • 2.60 GHz – 11 June 2003

Pentium 4 EE

edit
  • Introduced September 2003
  • "Extreme Edition"
  • Built from the Xeon's "Gallatin" core, but with 2 MB cache

Pentium 4E

edit
  • Introduced February 2004
  • Built on 0.09 μm (90 nm) process technology Prescott (2.4 A, 2.8, 2.8 A, 3.0, 3.2, 3.4, 3.6, 3.8 ) 1 MB L2 cache
  • 533 MHz system bus (2.4A and 2.8A only)
  • 800 MHz system bus (all other models)
  • 125 million transistors in 1 MB models
  • 169 million transistors in 2 MB models
  • Hyper-Threading support is only available on CPUs using the 800 MHz system bus.
  • The processor's integer instruction pipeline has been increased from 20 stages to 31 stages, which theoretically allows for even greater bandwidth
  • 7500 to 11,000 MIPS
  • LGA 775 versions are in the 5xx series (32-bit) and 5x1 series (with Intel 64)
  • The 6xx series has 2 MB L2 cache and Intel 64

64-bit processors: IA-64

edit

Itanium

edit
  • Code name Merced
  • Family 7
  • Released May 29, 2001
  • 733 MHz and 800 MHz
  • 2 MB cache
  • All recalled and replaced by Itanium 2

Itanium 2

edit
  • Family 0x1F
  • Released July 2002
  • 900 MHz – 1.6 GHz
  • McKinley 900 MHz 1.5 MB cache, Model 0x0
  • McKinley 1 GHz, 3 MB cache, Model 0x0
  • Deerfield 1 GHz, 1.5 MB cache, Model 0x1
  • Madison 1.3 GHz, 3 MB cache, Model 0x1
  • Madison 1.4 GHz, 4 MB cache, Model 0x1
  • Madison 1.5 GHz, 6 MB cache, Model 0x1
  • Madison 1.67 GHz, 9 MB cache, Model 0x1
  • Hondo 1.4 GHz, 4 MB cache, dual-core MCM, Model 0x1

64-bit processors: Intel 64 – NetBurst microarchitecture

edit
  • Intel Extended Memory 64 Technology
  • Mostly compatible with AMD's AMD64 architecture
  • Introduced Spring 2004, with the Pentium 4F (D0 and later P4 steppings)

Pentium 4F

edit
  • Prescott-2M built on 0.09 μm (90 nm) process technology
  • 2.8–3.8 GHz (model numbers 6x0)
  • Introduced February 20, 2005
  • Same features as Prescott with the addition of:
  • Cedar Mill built on 0.065 μm (65 nm) process technology
  • 3.0–3.6 GHz (model numbers 6x1)
  • Introduced January 16, 2006
  • Die shrink of Prescott-2M
  • Same features as Prescott-2M
  • Family 15 Model 4

Pentium D

edit
Main article: List of Intel Pentium D processors
  • Dual-core microprocessor
  • No Hyper-Threading
  • 800 (4×200) MHz front-side bus
  • LGA 775 (Socket T)
  • Smithfield (Pentium D) – 90 nm process technology (2.66–3.2 GHz)
    • Introduced May 26, 2005
    • 2.66–3.2 GHz (model numbers 805–840)
    • 230 million transistors
    • 1 MB × 2 (non-shared, 2 MB total) L2 cache
    • Cache coherency between cores requires communication over the FSB
    • Performance increase of 60% over similarly clocked Prescott
    • 2.66 GHz (533 MHz FSB) Pentium D 805 introduced December 2005
    • Contains 2× Prescott dies in one package
    • Family 15 Model 4
  • Presler (Pentium D) – 65 nm process technology (2.8–3.6 GHz)
    • Introduced January 16, 2006
    • 2.8–3.6 GHz (model numbers 915–960)
    • 376 million transistors
    • 2× 2 MB (non-shared, 4 MB total) L2 cache
    • Contains 2× Cedar Mill dies in one package
    • Variants
      • Pentium D 945

Pentium Extreme Edition

edit
  • Dual-core microprocessor
  • Enabled Hyper-Threading
  • 800 (4×200) MHz front-side bus
  • Smithfield (Pentium Extreme Edition) – 90 nm process technology (3.2 GHz)
    • Variants
      • Pentium 840 EE – 3.20 GHz (2 × 1 MB L2)
  • Presler (Pentium Extreme Edition) – 65 nm process technology (3.46, 3.73)
    • 2 MB × 2 (non-shared, 4 MB total) L2 cache
    • Variants

Xeon (64-bit NetBurst)

edit
  • Nocona
    • Introduced 2004
  • Irwindale
    • Introduced 2004
  • Cranford
    • Introduced April 2005
    • MP version of Nocona
  • Potomac
    • Introduced April 2005
    • Cranford with 8 MB of L3 cache
  • Paxville DP (2.8 GHz)
    • Introduced October 10, 2005
    • Dual-core version of Irwindale, with 4 MB of L2 cache (2 MB per core)
    • 2.8 GHz
    • 800 MT/s front-side bus
  • Paxville MP – 90 nm process (2.67 – 3.0 GHz)
    • Introduced November 1, 2005
    • Dual-core Xeon 7000 series
    • MP-capable version of Paxville DP
    • 2 MB of L2 cache (1 MB per core) or 4 MB of L2 (2 MB per core)
    • 667 MT/s FSB or 800 MT/s FSB
  • Dempsey – 65 nm process (2.67–3.73 GHz)
    • Introduced May 23, 2006
    • Dual-core Xeon 5000 series
    • MP version of Presler
    • 667 MT/s or 1066 MT/s FSB
    • 4 MB of L2 cache (2 MB per core)
    • LGA 771 (Socket J).
  • Tulsa – 65 nm process (2.5–3.4 GHz)
    • Introduced August 29, 2006
    • Dual-core Xeon 7100-series
    • Improved version of Paxville MP
    • 667 MT/s or 800 MT/s FSB

64-bit processors: Intel 64 – Core microarchitecture

edit

Xeon (64-bit Core microarchitecture)

edit
  • Woodcrest – 65 nm process technology
    • Server and Workstation CPU (SMP support for dual CPU system)
    • Introduced June 26, 2006
    • Intel VT-x, multiple OS support
    • EIST (Enhanced Intel SpeedStep Technology) in 5140, 5148LV, 5150, 5160
    • Execute Disable Bit
    • TXT, enhanced security hardware extensions
    • SSSE3 SIMD instructions
    • iAMT2 (Intel Active Management Technology), remotely manage computers
    • Variants
      • Xeon 5160, 3.00 GHz (4 MB L2, 1333 MHz FSB, 80 W)
      • Xeon 5150, 2.66 GHz (4 MB L2, 1333 MHz FSB, 65 W)
      • Xeon 5140, 2.33 GHz (4 MB L2, 1333 MHz FSB, 65 W)
      • Xeon 5130, 2.00 GHz (4 MB L2, 1333 MHz FSB, 65 W)
      • Xeon 5120, 1.86 GHz (4 MB L2, 1066 MHz FSB, 65 W)
      • Xeon 5110, 1.60 GHz (4 MB L2, 1066 MHz FSB, 65 W)
      • Xeon 5148LV, 2.33 GHz (4 MB L2, 1333 MHz FSB, 40 W) (low voltage edition)
  • Clovertown – 65 nm process technology
    • Server and Workstation CPU (SMP support for dual CPU system)
    • Introduced December 13, 2006
    • Quad-core
    • Intel VT-x, multiple OS support
    • EIST (Enhanced Intel SpeedStep Technology) in E5365, L5335
    • Execute Disable Bit
    • TXT, enhanced security hardware extensions
    • SSSE3 SIMD instructions
    • iAMT2 (Intel Active Management Technology), remotely manage computers
    • Variants
      • Xeon X5355, 2.66 GHz (2×4 MB L2, 1333 MHz FSB, 105 W)
      • Xeon E5345, 2.33 GHz (2×4 MB L2, 1333 MHz FSB, 80 W)
      • Xeon E5335, 2.00 GHz (2×4 MB L2, 1333 MHz FSB, 80 W)
      • Xeon E5320, 1.86 GHz (2×4 MB L2, 1066 MHz FSB, 65 W)
      • Xeon E5310, 1.60 GHz (2×4 MB L2, 1066 MHz FSB, 65 W)
      • Xeon L5320, 1.86 GHz (2×4 MB L2, 1066 MHz FSB, 50 W) (low voltage edition)

Intel Core 2

edit
  • Conroe – 65 nm process technology
    • Desktop CPU (SMP support restricted to 2 CPUs)
    • Two cores on one die
    • Introduced July 27, 2006
    • SSSE3 SIMD instructions
    • 291 million transistors
    • 64 KB of L1 cache per core (32+32 KB 8-way)
    • Intel VT-x, multiple OS support
    • TXT, enhanced security hardware extensions
    • Execute Disable Bit
    • EIST (Enhanced Intel SpeedStep Technology)
    • iAMT2 (Intel Active Management Technology), remotely manage computers
    • Intel Management Engine introduced
    • LGA 775
    • Variants
      • Core 2 Duo E6850, 3.00 GHz (4 MB L2, 1333 MHz FSB)
      • Core 2 Duo E6800, 2.93 GHz (4 MB L2, 1066 MHz FSB)
      • Core 2 Duo E6750, 2.67 GHz (4 MB L2, 1333 MHz FSB, 65 W)
      • Core 2 Duo E6700, 2.67 GHz (4 MB L2, 1066 MHz FSB)
      • Core 2 Duo E6600, 2.40 GHz (4 MB L2, 1066 MHz FSB, 65 W)
      • Core 2 Duo E6550, 2.33 GHz (4 MB L2, 1333 MHz FSB)
      • Core 2 Duo E6420, 2.13 GHz (4 MB L2, 1066 MHz FSB)
      • Core 2 Duo E6400, 2.13 GHz (2 MB L2, 1066 MHz FSB)
      • Core 2 Duo E6320, 1.86 GHz (4 MB L2, 1066 MHz FSB) Family 6, Model 15, Stepping 6
      • Core 2 Duo E6300, 1.86 GHz (2 MB L2, 1066 MHz FSB)
  • Conroe XE – 65 nm process technology
    • Desktop Extreme Edition CPU (SMP support restricted to 2 CPUs)
    • Introduced July 27, 2006
    • Same features as Conroe
    • LGA 775
    • Variants
      • Core 2 Extreme X6800 – 2.93 GHz (4 MB L2, 1066 MHz FSB)
  • Allendale (Intel Core 2) – 65 nm process technology
    • Desktop CPU (SMP support restricted to 2 CPUs)
    • Two CPUs on one die
    • Introduced January 21, 2007
    • SSSE3 SIMD instructions
    • 167 million transistors
    • TXT, enhanced security hardware extensions
    • Execute Disable Bit
    • EIST (Enhanced Intel SpeedStep Technology)
    • iAMT2 (Intel Active Management Technology), remotely manage computers
    • LGA 775
    • Variants
      • Core 2 Duo E4700, 2.60 GHz (2 MB L2, 800 MHz FSB)
      • Core 2 Duo E4600, 2.40 GHz (2 MB L2, 800 MHz FSB)
      • Core 2 Duo E4500, 2.20 GHz (2 MB L2, 800 MHz FSB)
      • Core 2 Duo E4400, 2.00 GHz (2 MB L2, 800 MHz FSB)
      • Core 2 Duo E4300, 1.80 GHz (2 MB L2, 800 MHz FSB) Family 6, Model 15, Stepping 2
  • Merom – 65 nm process technology
    • Mobile CPU (SMP support restricted to 2 CPUs)
    • Introduced July 27, 2006
    • Family 6, Model 15
    • Same features as Conroe
    • Socket M / Socket P / 479-ball Micro-FCBGA
    • Variants
      • Core 2 Extreme X7900 2.80 GHz (4 MB L2, 800 MHz FSB)
      • Core 2 Extreme X7800 2.60 GHz (4 MB L2, 800 MHz FSB)
      • Core 2 Duo T7800, 2.60 GHz (4 MB L2, 800 MHz FSB) (Santa Rosa platform)
      • Core 2 Duo T7700, 2.40 GHz (4 MB L2, 800 MHz FSB)
      • Core 2 Duo T7600, 2.33 GHz (4 MB L2, 667 MHz FSB)
      • Core 2 Duo T7500, 2.20 GHz (4 MB L2, 800 MHz FSB)
      • Core 2 Duo T7400, 2.16 GHz (4 MB L2, 667 MHz FSB)
      • Core 2 Duo T7300, 2.00 GHz (4 MB L2, 800 MHz FSB)
      • Core 2 Duo T7250, 2.00 GHz (2 MB L2, 800 MHz FSB)
      • Core 2 Duo T7200, 2.00 GHz (4 MB L2, 667 MHz FSB)
      • Core 2 Duo T7100, 1.80 GHz (2 MB L2, 800 MHz FSB)
      • Core 2 Duo T5600, 1.83 GHz (2 MB L2, 667 MHz FSB) Family 6, Model 15, Stepping 6
      • Core 2 Duo T5550, 1.83 GHz (2 MB L2, 667 MHz FSB, no VT)
      • Core 2 Duo T5500, 1.66 GHz (2 MB L2, 667 MHz FSB, no VT)
      • Core 2 Duo T5470, 1.60 GHz (2 MB L2, 800 MHz FSB, no VT) Family 6, Model 15, Stepping 13
      • Core 2 Duo T5450, 1.66 GHz (2 MB L2, 667 MHz FSB, no VT)
      • Core 2 Duo T5300, 1.73 GHz (2 MB L2, 533 MHz FSB, no VT)
      • Core 2 Duo T5270, 1.40 GHz (2 MB L2, 800 MHz FSB, no VT)
      • Core 2 Duo T5250, 1.50 GHz (2 MB L2, 667 MHz FSB, no VT)
      • Core 2 Duo T5200, 1.60 GHz (2 MB L2, 533 MHz FSB, no VT)
      • Core 2 Duo L7700, 1.80 GHz (4 MB L2, 800 MHz FSB) (low voltage) Family 6, Model 15, Stepping 11
      • Core 2 Duo L7500, 1.60 GHz (4 MB L2, 800 MHz FSB) (low voltage)
      • Core 2 Duo L7400, 1.50 GHz (4 MB L2, 667 MHz FSB) (low voltage)
      • Core 2 Duo L7300, 1.40 GHz (4 MB L2, 800 MHz FSB) (low voltage)
      • Core 2 Duo L7200, 1.33 GHz (4 MB L2, 667 MHz FSB) (low voltage)
      • Core 2 Duo U7700, 1.33 GHz (2 MB L2, 533 MHz FSB) (ultra low voltage)
      • Core 2 Duo U7600, 1.20 GHz (2 MB L2, 533 MHz FSB) (ultra low voltage)
      • Core 2 Duo U7500, 1.06 GHz (2 MB L2, 533 MHz FSB) (ultra low voltage)
      • Core 2 Duo U7100, 1.20 GHz (4 MB L2, 800 MHz FSB) (ultra low voltage) Family 6, Model 15, Stepping 11
      • Core 2 Solo U2100, 1.06 GHz (1 MB L2, 533 MHz FSB) (ultra low voltage)
      • Core 2 Solo U2200, 1.20 GHz (1 MB L2, 533 MHz FSB) (ultra low voltage)
  • Kentsfield – 65 nm process technology
    • Two dual-core CPU dies in one package
    • Desktop CPU quad-core (SMP support restricted to 4 CPUs)
    • Introduced December 13, 2006
    • Same features as Conroe but with 4 CPU cores
    • 586 million transistors
    • LGA 775
    • Family 6, Model 15, Stepping 11
    • Variants
      • Core 2 Extreme QX6850, 3 GHz (2×4 MB L2 cache, 1333 MHz FSB)
      • Core 2 Extreme QX6800, 2.93 GHz (2×4 MB L2 cache, 1066 MHz FSB) (April 9, 2007)
      • Core 2 Extreme QX6700, 2.66 GHz (2×4 MB L2 cache, 1066 MHz FSB) (November 14, 2006)
      • Core 2 Quad Q6700, 2.66 GHz (2×4 MB L2 cache, 1066 MHz FSB) (July 22, 2007)
      • Core 2 Quad Q6600, 2.40 GHz (2×4 MB L2 cache, 1066 MHz FSB) (January 7, 2007)
  • Wolfdale – 45 nm process technology
    • Die shrink of Conroe
    • Same features as Conroe with the addition of:
      • 50% more cache, 6 MB as opposed to 4 MB
      • Intel Trusted Execution Technology
      • SSE4 SIMD instructions
    • 410 million transistors
    • Variants
      • Core 2 Duo E8600, 3.33 GHz (6 MB L2, 1333 MHz FSB)
      • Core 2 Duo E8500, 3.16 GHz (6 MB L2, 1333 MHz FSB)
      • Core 2 Duo E8435, 3.07 GHz (6 MB L2, 1066 MHz FSB)
      • Core 2 Duo E8400, 3.00 GHz (6 MB L2, 1333 MHz FSB)
      • Core 2 Duo E8335, 2.93 GHz (6 MB L2, 1066 MHz FSB)
      • Core 2 Duo E8300, 2.83 GHz (6 MB L2, 1333 MHz FSB)
      • Core 2 Duo E8235, 2.80 GHz (6 MB L2, 1066 MHz FSB)
      • Core 2 Duo E8200, 2.66 GHz (6 MB L2, 1333 MHz FSB)
      • Core 2 Duo E8135, 2.66 GHz (6 MB L2, 1066 MHz FSB)
      • Core 2 Duo E8190, 2.66 GHz (6 MB L2, 1333 MHz FSB, no TXT, no VT)
  • Wolfdale-3M (Intel Core 2) – 45 nm process technology
    • Intel Trusted Execution Technology
    • Variants
      • Core 2 Duo E7600, 3.06 GHz (3 MB L2, 1066 MHz FSB)
      • Core 2 Duo E7500, 2.93 GHz (3 MB L2, 1066 MHz FSB)
      • Core 2 Duo E7400, 2.80 GHz (3 MB L2, 1066 MHz FSB)
      • Core 2 Duo E7300, 2.66 GHz (3 MB L2, 1066 MHz FSB)
      • Core 2 Duo E7200, 2.53 GHz (3 MB L2, 1066 MHz FSB)
  • Yorkfield, 45 nm process technology
    • Quad-core CPU
    • Die shrink of Kentsfield
    • Contains 2× Wolfdale dual-core dies in one package
    • Same features as Wolfdale
    • 820 million transistors
    • Variants
      • Core 2 Extreme QX9770, 3.20 GHz (2×6 MB L2, 1600 MHz FSB)
      • Core 2 Extreme QX9650, 3.00 GHz (2×6 MB L2, 1333 MHz FSB)
      • Core 2 Quad Q9705, 3.16 GHz (2×3 MB L2, 1333 MHz FSB)
      • Core 2 Quad Q9700, 3.16 GHz (2×3 MB L2, 1333 MHz FSB)
      • Core 2 Quad Q9650, 3 GHz (2×6 MB L2, 1333 MHz FSB)
      • Core 2 Quad Q9550, 2.83 GHz (2×6 MB L2, 1333 MHz FSB, 95 W TDP)
      • Core 2 Quad Q9550s, 2.83 GHz (2×6 MB L2, 1333 MHz FSB, 65 W TDP)
      • Core 2 Quad Q9450, 2.66 GHz (2×6 MB L2, 1333 MHz FSB, 95 W TDP)
      • Core 2 Quad Q9505, 2.83 GHz (2×3 MB L2, 1333 MHz FSB, 95 W TDP)
      • Core 2 Quad Q9505s, 2.83 GHz (2×3 MB L2, 1333 MHz FSB, 65 W TDP)
      • Core 2 Quad Q9500, 2.83 GHz (2×3 MB L2, 1333 MHz FSB, 95 W TDP, no TXT)
      • Core 2 Quad Q9400, 2.66 GHz (2×3 MB L2, 1333 MHz FSB, 95 W TDP)
      • Core 2 Quad Q9400s, 2.66 GHz (2×3 MB L2, 1333 MHz FSB, 65 W TDP)
      • Core 2 Quad Q9300, 2.50 GHz (2×3 MB L2, 1333 MHz FSB, 95 W TDP)
      • Core 2 Quad Q8400, 2.66 GHz (2×2 MB L2, 1333 MHz FSB, 95 W TDP)
      • Core 2 Quad Q8400s, 2.66 GHz (2×2 MB L2, 1333 MHz FSB, 65 W TDP)
      • Core 2 Quad Q8300, 2.50 GHz (2×2 MB L2, 1333 MHz FSB, 95 W TDP)
      • Core 2 Quad Q8300s, 2.50 GHz (2×2 MB L2, 1333 MHz FSB, 65 W TDP)
      • Core 2 Quad Q8200, 2.33 GHz (2×2 MB L2, 1333 MHz FSB, 95 W TDP)
      • Core 2 Quad Q8200s, 2.33 GHz (2×2 MB L2, 1333 MHz FSB, 65 W TDP)
      • Core 2 Quad Q7600, 2.70 GHz (2×1 MB L2, 800 MHz FSB, no SSE4) (no Q7600 listed here)
  • Intel Core2 Quad Mobile processor family – 45 nm process technology
    • Quad-core CPU
    • Variants
      • Core 2 Quad Q9100, 2.26 GHz (2×6 MB L2, 1066 MHz FSB, 45 W TDP)
      • Core 2 Quad Q9000, 2.00 GHz (2×3 MB L2, 1066 MHz FSB, 45 W TDP)

Pentium Dual-Core

edit
  • Allendale (Pentium Dual-Core) – 65 nm process technology
    • Desktop CPU (SMP support restricted to 2 CPUs)
    • Two cores on one die
    • Introduced January 21, 2007
    • SSSE3 SIMD instructions
    • 167 million transistors
    • TXT, enhanced security hardware extensions
    • Execute Disable Bit
    • EIST (Enhanced Intel SpeedStep Technology)
    • Variants
      • Intel Pentium E2220, 2.40 GHz (1 MB L2, 800 MHz FSB)
      • Intel Pentium E2200, 2.20 GHz (1 MB L2, 800 MHz FSB)
      • Intel Pentium E2180, 2.00 GHz (1 MB L2, 800 MHz FSB)
      • Intel Pentium E2160, 1.80 GHz (1 MB L2, 800 MHz FSB)
      • Intel Pentium E2140, 1.60 GHz (1 MB L2, 800 MHz FSB)
  • Wolfdale-3M (Pentium Dual-Core) – 45 nm process technology
    • Intel Pentium E6800, 3.33 GHz (2 MB L2,1066 MHz FSB)
    • Intel Pentium E6700, 3.20 GHz (2 MB L2,1066 MHz FSB)
    • Intel Pentium E6600, 3.06 GHz (2 MB L2,1066 MHz FSB)
    • Intel Pentium E6500, 2.93 GHz (2 MB L2,1066 MHz FSB)
    • Intel Pentium E6300, 2.80 GHz (2 MB L2,1066 MHz FSB)
    • Intel Pentium E5800, 3.20 GHz (2 MB L2, 800 MHz FSB)
    • Intel Pentium E5700, 3.00 GHz (2 MB L2, 800 MHz FSB)
    • Intel Pentium E5500, 2.80 GHz (2 MB L2, 800 MHz FSB)
    • Intel Pentium E5400, 2.70 GHz (2 MB L2, 800 MHz FSB)
    • Intel Pentium E5300, 2.60 GHz (2 MB L2, 800 MHz FSB)
    • Intel Pentium E5200, 2.50 GHz (2 MB L2, 800 MHz FSB)
    • Intel Pentium E2210, 2.20 GHz (1 MB L2, 800 MHz FSB)

Celeron (64-bit Core microarchitecture)

edit
  • Allendale (Celeron, 64-bit Core microarchitecture) – 65 nm process technology
    • Variants
      • Intel Celeron E1600, 2.40 GHz (512 KB L2, 800 MHz FSB)
      • Intel Celeron E1500, 2.20 GHz (512 KB L2, 800 MHz FSB)
      • Intel Celeron E1400, 2.00 GHz (512 KB L2, 800 MHz FSB)
      • Intel Celeron E1200, 1.60 GHz (512 KB L2, 800 MHz FSB)
  • Wolfdale-3M (Celeron, 64-bit Core microarchitecture) – 45 nm process technology
    • Variants
      • Intel Celeron E3500, 2.70 GHz (1 MB L2, 800 MHz FSB)
      • Intel Celeron E3400, 2.60 GHz (1 MB L2, 800 MHz FSB)
      • Intel Celeron E3300, 2.50 GHz (1 MB L2, 800 MHz FSB)
      • Intel Celeron E3200, 2.40 GHz (1 MB L2, 800 MHz FSB)
  • Conroe-L (Celeron, 64-bit Core microarchitecture) – 65 nm process technology
    • Variants
      • Intel Celeron 450, 2.20 GHz (512 KB L2, 800 MHz FSB)
      • Intel Celeron 440, 2.00 GHz (512 KB L2, 800 MHz FSB)
      • Intel Celeron 430, 1.80 GHz (512 KB L2, 800 MHz FSB)
      • Intel Celeron 420, 1.60 GHz (512 KB L2, 800 MHz FSB)
      • Intel Celeron 220, 1.20 GHz (512 KB L2, 533 MHz FSB)
  • Conroe-CL (Celeron, 64-bit Core microarchitecture) – 65 nm process technology
    • LGA 771 package
    • Variants
      • Intel Celeron 445, 1.87 GHz (512 KB L2, 1066 MHz FSB)

Celeron M (64-bit Core microarchitecture)

edit
  • Merom-L 65 nm process technology
    • 64 KB L1 cache
    • 1 MB L2 cache (integrated)
    • SSE3 SIMD instructions, 533 MHz/667 MHz front-side bus, execute-disable bit, 64-bit
    • No SpeedStep technology, is not part of the 'Centrino' package
    • Variants
      • 520, 1.60 GHz
      • 530, 1.73 GHz
      • 540, 1.86 GHz
      • 550, 2.00 GHz
      • 560, 2.13 GHz
      • 570, 2.26 GHz
      • 667 MHz FSB
        • 575, 2.00 GHz
        • 585, 2.16 GHz

64-bit processors: Intel 64 – Nehalem microarchitecture

edit

Intel Pentium (Nehalem)

edit
  • Clarkdale (Pentium, Nehalem microarchitecture) – 32 nm process technology (manufacturing 7 Jan 2010)
    • 2 physical cores/2 threads
    • 32+32 KB L1 cache
    • 256 KB L2 cache
    • 3 MB L3 cache
    • Introduced January 2010
    • Socket 1156 LGA
    • 2-channel DDR3
    • Integrated HD GPU
    • Variants

Core i3 (1st generation)

edit
  • Clarkdale (Core i3 1st generation) – 32 nm process technology
    • 2 physical cores/4 threads
    • 32+32 KB L1 cache
    • 256 KB L2 cache
    • 4 MB L3 cache
    • Introduced on January 7, 2010
    • Socket 1156 LGA
    • 2-channel DDR3
    • Integrated HD GPU
    • Variants
      • 530, 2.93 GHz Hyper-Threading
      • 540, 3.06 GHz Hyper-Threading
      • 550, 3.2 GHz Hyper-Threading
      • 560, 3.33 GHz Hyper-Threading

Core i5 (1st generation)

edit
  • Lynnfield (Core i5 1st generation) – 45 nm process technology
    • 4 physical cores/4 threads
    • 32+32 KB L1 cache
    • 256 KB L2 cache
    • 8 MB L3 cache
    • Introduced September 8, 2009
    • Family 6 Model E (Ext. Model 1E)
    • Socket 1156 LGA
    • 2-channel DDR3
    • Variants
      • 750S, 2.40 GHz/3.20 GHz Turbo Boost
      • 750, 2.66 GHz/3.20 GHz Turbo Boost
      • 760, 2.80 GHz/3.33 GHz Turbo Boost
  • Clarkdale (Core i5 1st generation) – 32 nm process technology
    • 2 physical cores/4 threads
    • 32+32 KB L1 cache
    • 256 KB L2 cache
    • 4 MB L3 cache
    • Introduced January, 2010
    • Socket 1156 LGA
    • 2-channel DDR3
    • Integrated HD GPU
    • AES Support
    • Variants
      • 650/655K, 3.2 GHz Hyper-Threading Turbo Boost
      • 660/661, 3.33 GHz Hyper-Threading Turbo Boost
      • 670, 3.46 GHz Hyper-Threading Turbo Boost
      • 680, 3.60 GHz Hyper-Threading Turbo Boost

Core i7 (1st generation)

edit
  • Bloomfield (Core i7 1st generation) – 45 nm process technology
    • 4 physical cores/8 threads
    • 256 KB L2 cache
    • 8 MB L3 cache
    • Front-side bus replaced with QuickPath up to 6.4 GT/s
    • Hyper-Threading is again included. This had previously been removed at the introduction of Core line
    • 781 million transistors
    • Intel Turbo Boost Technology
    • TDP 130 W
    • Introduced November 17, 2008
    • Socket 1366 LGA
    • 3-channel DDR3
    • Variants
      • 975 (extreme edition), 3.33 GHz/3.60 GHz Turbo Boost
      • 965 (extreme edition), 3.20 GHz/3.46 GHz Turbo Boost
      • 960, 3.20 GHz/3.46 GHz Turbo Boost
      • 950, 3.06 GHz/3.33 GHz Turbo Boost
      • 940, 2.93 GHz/3.20 GHz Turbo Boost
      • 930, 2.80 GHz/3.06 GHz Turbo Boost
      • 920, 2.66 GHz/2.93 GHz Turbo Boost
  • Lynnfield (Core i7 1st generation) – 45 nm process technology
    • 4 physical cores/8 threads
    • 32+32 KB L1 cache
    • 256 KB L2 cache
    • 8 MB L3 cache
    • No QuickPath, instead compatible with slower DMI interface
    • Hyper-Threading is included
    • Introduced September 8, 2009
    • Socket 1156 LGA
    • 2-channel DDR3
    • Variants
      • 880, 3.06 GHz/3.73 GHz Turbo Boost (TDP 95 W)
      • 870/875K, 2.93 GHz/3.60 GHz Turbo Boost (TDP 95 W)
      • 870S, 2.67 GHz/3.60 GHz Turbo Boost (TDP 82 W)
      • 860, 2.80 GHz/3.46 GHz Turbo Boost (TDP 95 W)
      • 860S, 2.53 GHz/3.46 GHz Turbo Boost (TDP 82 W)

Westmere

  • Gulftown, 32 nm process technology
    • 6 physical cores
    • 256 KB L2 cache
    • 12 MB L3 cache
    • Front-side bus replaced with QuickPath up to 6.4 GT/s
    • Hyper-Threading is included
    • Intel Turbo Boost Technology
    • Socket 1366 LGA
    • TDP 130 W
    • Introduced 16 March 2010
    • Variants
      • 990X Extreme Edition, 3.46 GHz/3.73 GHz Turbo Boost
      • 980X Extreme Edition, 3.33 GHz/3.60 GHz Turbo Boost
      • 970, 3.20 GHz/3.46 GHz Turbo Boost
  • Clarksfield – Intel Core i7 Mobile processor family – 45 nm process technology
    • 4 physical cores
    • Hyper-Threading is included
    • Intel Turbo Boost Technology
    • Variants
      • 940XM Extreme Edition, 2.13 GHz/3.33 GHz Turbo Boost (8 MB L3, TDP 55 W)
      • 920XM Extreme Edition, 2.00 GHz/3.20 GHz Turbo Boost (8 MB L3, TDP 55 W)
      • 840QM, 1.86 GHz/3.20 GHz Turbo Boost (8 MB L3, TDP 45 W)
      • 820QM, 1.73 GHz/3.06 GHz Turbo Boost (8 MB L3, TDP 45 W)
      • 740QM, 1.73 GHz/2.93 GHz Turbo Boost (6 MB L3, TDP 45 W)
      • 720QM, 1.60 GHz/2.80 GHz Turbo Boost (6 MB L3, TDP 45 W)

Xeon (Nehalem microarchitecture)

edit
  • Gainestown – 45 nm process technology
    • Same processor dies as Bloomfield
    • 256 KB L2 cache
    • 8 MB L3 cache, 4 MB may be disabled
    • QuickPath up to 6.4 GT/s
    • Hyper-Threading is included in some models
    • 781 million transistors
    • Introduced March 29, 2009
    • Variants
      • W5590, X5570, X5560, X5550, E5540, E5530, L5530, E5520, L5520, L5518, 4 cores, 8 MB L3 cache, HT
      • E5506, L5506, E5504, 4 cores, 4 MB L3 cache, no HT
      • L5508, E5502, E5502, 2 cores, 4 MB L3 cache, no HT

64-bit processors: Intel 64 – Sandy Bridge / Ivy Bridge microarchitecture

edit

Celeron (Sandy Bridge/Ivy Bridge microarchitecture)

edit
  • Sandy Bridge (Celeron-branded) – 32 nm process technology
    • 2 physical cores/2 threads (500 series), 1 physical core/1 thread (model G440) or 1 physical core/2 threads (models G460 & G465)
    • 2 MB L3 cache (500 series), 1 MB (model G440) or 1.5 MB (models G460 & G465)
    • Introduced 3rd quarter, 2011
    • Socket 1155 LGA
    • 2-channel DDR3-1066
    • 400 series has max TDP of 35 W
    • 500-series variants ending in 'T' have a peak TDP of 35 W; others, 65 W
    • Integrated GPU
      • All variants have peak GPU turbo frequencies of 1 GHz
      • Variants in the 400 series have GPUs running at a base frequency of 650 MHz
      • Variants in the 500 series ending in 'T' have GPUs running at a base frequency of 650 MHz; others at 850 MHz
      • All variants have 6 GPU execution units
    • Variants
      • G440, 1.6 GHz
      • G460, 1.8 GHz
      • G465, 1.9 GHz
      • G470, 2.0 GHz
      • G530T, 2.0 GHz
      • G540T, 2.1 GHz
      • G550T, 2.2 GHz
      • G530, 2.4 GHz
      • G540, 2.5 GHz
      • G550, 2.6 GHz
      • G555, 2.7 GHz

Pentium (Sandy Bridge/Ivy Bridge microarchitecture)

edit
  • Sandy Bridge (Pentium-branded) – 32 nm process technology
    • 2 physical cores/2 threads
    • 3 MB L3 cache
    • 624 million transistors
    • Introduced May, 2011
    • Socket 1155 LGA
    • 2-channel DDR3-1333 (800 series) or DDR3-1066 (600 series)
    • Variants ending in 'T' have a peak TDP of 35 W, others 65 W
    • Integrated GPU (HD 2000)
      • All variants have peak GPU turbo frequencies of 1.1 GHz
      • Variants ending in 'T' have GPUs running at a base frequency of 650 MHz; others at 850 MHz
      • All variants have 6 GPU execution units
    • Variants
      • G620T, 2.2 GHz
      • G630T, 2.3 GHz
      • G640T, 2.4 GHz
      • G645T, 2.5 GHz
      • G860T, 2.6 GHz
      • G620, 2.6 GHz
      • G622, 2.6 GHz
      • G630, 2.7 GHz
      • G632, 2.7 GHz
      • G640, 2.8 GHz
      • G840, 2.8 GHz
      • G645, 2.9 GHz
      • G850, 2.9 GHz
      • G860, 3.0 GHz
      • G870, 3.1 GHz
  • Ivy Bridge (Pentium-branded) – 22 nm tri-gate transistor process technology
    • 2 physical cores/2 threads
    • 32+32 KB (per core) L1 cache
    • 256 KB (per core) L2 cache
    • 3 MB L3 cache
    • Introduced September, 2012
    • Socket 1155 LGA
    • 2-channel DDR3-1333 for G2000 series
    • 2-channel DDR3-1600 for G2100 series
    • All variants have GPU base frequencies of 650 MHz and peak GPU turbo frequencies of 1.05 GHz
    • Variants ending in 'T' have a peak TDP of 35 W; others, TDP of 55 W
    • Variants
      • G2020T, 2.5 GHz
      • G2030T, 2.6 GHz
      • G2100T, 2.6 GHz
      • G2120T, 2.7 GHz
      • G2010, 2.8 GHz
      • G2020, 2.9 GHz
      • G2030, 3.0 GHz
      • G2120, 3.1 GHz
      • G2130, 3.2 GHz
      • G2140, 3.3 GHz

Core i3 (2nd and 3rd generation)

edit
  • Sandy Bridge (Core i3 2nd generation) – 32 nm process technology
    • 2 physical cores/4 threads
    • 32+32 KB (per core) L1 cache
    • 256 KB (per core) L2 cache
    • 3 MB L3 cache
    • 624 million transistors
    • Introduced January, 2011
    • Socket 1155 LGA
    • 2-channel DDR3-1333
    • Variants ending in 'T' have a peak TDP of 35 W, others 65 W
    • Integrated GPU
      • All variants have peak GPU turbo frequencies of 1.1 GHz
      • Variants ending in 'T' have GPUs running at a base frequency of 650 MHz; others at 850 MHz
      • Variants ending in '5' have Intel HD Graphics 3000 (12 execution units); others have Intel HD Graphics 2000 (6 execution units)
    • Variants
      • i3-2100T, 2.5 GHz
      • i3-2120T, 2.6 GHz
      • i3-2100, 3.1 GHz
      • i3-2102, 3.1 GHz
      • i3-2105, 3.1 GHz
      • i3-2120, 3.3 GHz
      • i3-2125, 3.3 GHz
      • i3-2130, 3.4 GHz
  • Ivy Bridge (Core i3 3rd generation) – 22 nm tri-gate transistor process technology
    • 2 physical cores/4 threads
    • 32+32 KB (per core) L1 cache
    • 256 KB (per core) L2 cache
    • 3 MB L3 cache
    • Introduced September, 2012
    • Socket 1155 LGA
    • 2-channel DDR3-1600
    • Variants ending in '5' have Intel HD Graphics 4000; others have Intel HD Graphics 2500
    • All variants have GPU base frequencies of 650 MHz and peak GPU turbo frequencies of 1.05 GHz
    • TDP 55 W
    • Variants
      • i3-3220T, 2.8 GHz
      • i3-3240T, 2.9 GHz
      • i3-3210, 3.2 GHz
      • i3-3220, 3.3 GHz
      • i3-3225, 3.3 GHz
      • i3-3240, 3.4 GHz
      • i3-3250, 3.5 GHz

Core i5 (2nd and 3rd generation)

edit
  • Sandy Bridge (Core i5 2nd generation) – 32 nm process technology
    • 4 physical cores/4 threads (except for i5-2390T which has 2 physical cores/4 threads)
    • 32+32 KB (per core) L1 cache
    • 256 KB (per core) L2 cache
    • 6 MB L3 cache (except for i5-2390T which has 3 MB)
    • 995 million transistors
    • Introduced January, 2011
    • Socket 1155 LGA
    • 2-channel DDR3-1333
    • Variants ending in 'S' have a peak TDP of 65 W; others, 95 W except where noted
    • Variants ending in 'K' have unlocked multipliers; others cannot be overclocked
    • Integrated GPU
      • i5-2500T has a peak GPU turbo frequency of 1.25 GHz, others 1.1 GHz
      • Variants ending in 'T' have GPUs running at a base frequency of 650 MHz; others at 850 MHz
      • Variants ending in '5' or 'K' have Intel HD Graphics 3000 (12 execution units), except i5-2550K which has no GPU; others have Intel HD Graphics 2000 (6 execution units)
      • Variants ending in 'P' and the i5-2550K have no GPU
    • Variants
      • i5-2390T, 2.7 GHz/3.5 GHz Turbo Boost (35 W max. TDP)
      • i5-2500T, 2.3 GHz/3.3 GHz Turbo Boost (45 W max. TDP)
      • i5-2400S, 2.5 GHz/3.3 GHz Turbo Boost
      • i5-2405S, 2.5 GHz/3.3 GHz Turbo Boost
      • i5-2500S, 2.7 GHz/3.7 GHz Turbo Boost
      • i5-2300, 2.8 GHz/3.1 GHz Turbo Boost
      • i5-2310, 2.9 GHz/3.2 GHz Turbo Boost
      • i5-2320, 3.0 GHz/3.3 GHz Turbo Boost
      • i5-2380P, 3.1 GHz/3.4 GHz Turbo Boost
      • i5-2400, 3.1 GHz/3.4 GHz Turbo Boost
      • i5-2450P, 3.2 GHz/3.5 GHz Turbo Boost
      • i5-2500, 3.3 GHz/3.7 GHz Turbo Boost
      • i5-2500K, 3.3 GHz/3.7 GHz Turbo Boost
      • i5-2550K, 3.4 GHz/3.8 GHz Turbo Boost
  • Ivy Bridge (Core i5 3rd generation) – 22 nm Tri-gate transistor process technology
    • 4 physical cores/4 threads (except for i5-3470T which has 2 physical cores/4 threads)
    • 32+32 KB (per core) L1 cache
    • 256 KB (per core) L2 cache
    • 6 MB L3 cache (except for i5-3470T which has 3 MB)
    • Introduced April, 2012
    • Socket 1155 LGA
    • 2-channel DDR3-1600
    • Variants ending in 'S' have a peak TDP of 65 W, Variants ending in 'T' have a peak TDP of 35 or 45 W (see variants); others, 77 W except where noted
    • Variants ending in 'K' have unlocked multipliers; others cannot be overclocked
    • Variants ending in 'P' have no integrated GPU; others have Intel HD Graphics 2500 or Intel HD Graphics 4000 (i5-3475S and i5-3570K only)
    • Variants
      • i5-3470T, 2.9 GHz/3.6 GHz max Turbo Boost (35 W TDP)
      • i5-3570T, 2.3 GHz/3.3 GHz max Turbo Boost (45 W TDP)
      • i5-3330S, 2.7 GHz/3.2 GHz max Turbo Boost
      • i5-3450S, 2.8 GHz/3.5 GHz max Turbo Boost
      • i5-3470S, 2.9 GHz/3.6 GHz max Turbo Boost
      • i5-3475S, 2.9 GHz/3.6 GHz max Turbo Boost
      • i5-3550S, 3.0 GHz/3.7 GHz max Turbo Boost
      • i5-3570S, 3.1 GHz/3.8 GHz max Turbo Boost
      • i5-3330, 3.0 GHz/3.2 GHz max Turbo Boost
      • i5-3350P, 3.1 GHz/3.3 GHz max Turbo Boost (69 W TDP)
      • i5-3450, 3.1 GHz/3.5 GHz max Turbo Boost
      • i5-3470, 3.2 GHz/3.6 GHz max Turbo Boost
      • i5-3550, 3.3 GHz/3.7 GHz max Turbo Boost
      • i5-3570, 3.4 GHz/3.8 GHz max Turbo Boost
      • i5-3570K, 3.4 GHz/3.8 GHz max Turbo Boost

Core i7 (2nd and 3rd generation)

edit
  • Sandy Bridge (Core i7 2nd generation) – 32 nm process technology
    • 4 physical cores/8 threads
    • 32+32 KB (per core) L1 cache
    • 256 KB (per core) L2 cache
    • 8 MB L3 cache
    • 995 million transistors
    • Introduced January, 2011
    • Socket 1155 LGA
    • 2-channel DDR3-1333
    • Variants ending in 'S' have a peak TDP of 65 W, others – 95 W
    • Variants ending in 'K' have unlocked multipliers; others cannot be overclocked
    • Integrated GPU
      • All variants have base GPU frequencies of 850 MHz and peak GPU turbo frequencies of 1.35 GHz
      • Variants ending in 'K' have Intel HD Graphics 3000 (12 execution units); others have Intel HD Graphics 2000 (6 execution units)
    • Variants
      • i7-2600S, 2.8 GHz/3.8 GHz Turbo Boost
      • i7-2600, 3.4 GHz/3.8 GHz Turbo Boost
      • i7-2600K, 3.4 GHz/3.8 GHz Turbo Boost
      • i7-2700K, 3.5 GHz/3.9 GHz Turbo Boost
  • Sandy Bridge-E (Core i7 3rd generation X-Series) – 32 nm process technology
    • Up to 6 physical cores/12 threads depending on model number
    • 32+32 KB (per core) L1 cache
    • 256 KB (per core) L2 cache
    • Up to 20 MB L3 cache depending on model number
    • 2.27 billion transistors
    • Introduced November, 2011
    • Socket 2011 LGA
    • 4-channel DDR3-1600
    • All variants have a peak TDP of 130 W
    • No integrated GPU
    • Variants (all marketed under "Intel Core X-series processors")[35]
      • i7-3820, 3.6 GHz/3.8 GHz Turbo Boost, 4 cores, 10 MB L3 cache
      • i7-3930K, 3.2 GHz/3.8 GHz Turbo Boost, 6 cores, 12 MB L3 cache
      • i7-3960X, 3.3 GHz/3.9 GHz Turbo Boost, 6 cores, 15 MB L3 cache
      • i7-3970X, 3.5 GHz/4.0 GHz Turbo Boost, 6 cores, 15 MB L3 cache
  • Ivy Bridge (Core i7 3rd generation) – 22 nm Tri-gate transistor process technology
    • 4 physical cores/8 threads
    • 32+32 KB (per core) L1 cache
    • 256 KB (per core) L2 cache
    • 8 MB L3 cache
    • Introduced April, 2012
    • Socket 1155 LGA
    • 2-channel DDR3-1600
    • Variants ending in 'S' have a peak TDP of 65 W, variants ending in 'T' have a peak TDP of 45 W, others – 77 W
    • Variants ending in 'K' have unlocked multipliers; others cannot be overclocked
    • Integrated GPU Intel HD Graphics 4000
    • Variants
      • i7-3770T – 2.5 GHz/3.7 GHz Turbo Boost
      • i7-3770S – 3.1 GHz/3.9 GHz Turbo Boost
      • i7-3770 – 3.4 GHz/3.9 GHz Turbo Boost
      • i7-3770K – 3.5 GHz/3.9 GHz Turbo Boost

64-bit processors: Intel 64 – Haswell microarchitecture

edit
Main article: Haswell (microarchitecture)

Core i3 (4th generation)

edit
  • Haswell (Core i3 4th generation) – 22nm process technology
    • 2 physical cores/4 threads
    • 4 MB L3 cache
    • Introduced Q2'13
    • Socket 1150 LGA
    • 2-channel DDR3L-1333/1600
    • Integrated GPU
    • Variants
      • i3-4370 – 3.8 GHz


Core i5 (4th generation)

edit
  • Haswell (Core i5 4th generation) – 22nm process technology
    • 4 physical cores/4 threads
    • 4 MB L3 cache
    • Introduced Q2'13
    • Socket 1150 LGA
    • 2-channel DDR3L-1333/1600
    • Integrated GPU
    • Variants
      • i5-4460 – 3.2 GHz/3.40 GHz Turbo Boost
      • i5-4590 – 3.7 GHz/3.70 GHz Turbo Boost
      • i5-4690 – 3.5 GHz/3.90 GHz Turbo Boost

64-bit processors: Intel 64 – Broadwell microarchitecture

edit

Core i3 (5th generation)

edit

Core i5 (5th generation)

edit
  • Broadwell (Core i5 5th generation) – 14nm process technology
    • 4 physical cores/4 threads
    • 4 MB L3 cache
    • Introduced Q2'15
    • Socket 1150 LGA
    • 2-channel DDR3L-1333/1600
    • Integrated GPU
    • Variants
      • i5-5575R – 2.80 GHz/3.30 GHz Turbo Boost
      • i5-5675C – 3.10 GHz/3.60 GHz Turbo Boost
      • i5-5675R – 3.10 GHz/3.60 GHz Turbo Boost

Core i7 (5th generation, Including Core-X Series)

edit
  • Broadwell (Core i7 5th generation) – 14nm process technology
    • 4 physical cores/8 threads
    • 6 MB L3 cache
    • Introduced Q2'15
    • Socket 1150 LGA
    • 2-channel DDR3L-1333/1600
    • Integrated GPU
    • Variants
      • i7-5775C – 3.30 GHz/3.70 GHz Turbo Boost
      • i7-5775R – 3.30 GHz/3.80 GHz Turbo Boost
  • Broadwell-E – 14nm process technology
    • 6–10 physical cores/12–20 threads
    • 15–25 MB L3 cache
    • Introduced Q2'16
    • Socket 2011-v3 LGA
    • 4-channel DDR4-2133/2400
    • No Integrated GPU
    • Variants (all marketed under "Intel Core X-series processors")[35]
      • i7-6800K – 3.40 GHz/3.60 GHz Turbo Boost/3.80 GHz Turbo Boost Max Technology 3.0 Frequency 15 MB L3 cache
      • i7-6850K – 3.60 GHz/3.80 GHz Turbo Boost/4.00 GHz Turbo Boost Max Technology 3.0 Frequency 15 MB L3 cache
      • i7-6900K – 3.20 GHz/3.70 GHz Turbo Boost/4.00 GHz Turbo Boost Max Technology 3.0 Frequency 20 MB L3 cache
      • i7-6950X – 3.00 GHz/3.50 GHz Turbo Boost/4.00 GHz Turbo Boost Max Technology 3.0 Frequency 25 MB L3 cache

Other Broadwell CPUs

edit

Not listed (yet) are several Broadwell-based CPU models:[36]

  • Server and workstation CPUs
    • single-CPU: Pentium D15nn, Xeon D-15nn, Xeon E3-12nn v4, Xeon E5-16nn v4
    • dual-CPU: Xeon E5-26nn v4
    • quad-CPU: Xeon E5-46nn v4, Xeon E7-48nn v4
    • octo-CPU: Xeon E7-88nn v4
  • Embedded CPUs
    • Core i7-57nnEQ, Core i7-58nnEQ
  • Mobile CPUs
    • Celeron 32nnU, Celeron 37nnU
    • Pentium 38nnU
    • Core M-5Ynn
    • Core i3-50nnU
    • Core i5-5nnnU
    • Core i7-55nnU, Core i7-56nnU, Core i7-57nnHQ, Core i7-59nnHQ

Note: this list does not say that all processors that match these patterns are Broadwell-based or fit into this scheme. The model numbers may have suffixes that are not shown here.

64-bit processors: Intel 64 – Skylake microarchitecture

edit

Core i3 (6th generation)

edit
  • Skylake (Core i3 6th generation) – 14 nm process technology
    • 2 physical cores/4 threads
    • 3–4 MB L3 cache
    • Introduced Q3'15
    • Socket 1151 LGA
    • 2-channel DDR3L-1333/1600, DDR4-1866/2133
    • Integrated GPU Intel HD Graphics 530 (only i3-6098P have HD Graphics 510)
    • Variants
      • i3-6098P – 3.60 GHz
      • i3-6100T – 3.20 GHz
      • i3-6100 – 3.70 GHz
      • i3-6300T – 3.30 GHz
      • i3-6300 – 3.80 GHz
      • i3-6320 – 3.90 GHz

Core i5 (6th generation)

edit
  • Skylake (Core i5 6th generation) – 14nm process technology
    • 4 physical cores/4 threads
    • 6 MB L3 cache
    • Introduced Q3'15
    • Socket 1151 LGA
    • 2-channel DDR3L-1333/1600, DDR4-1866/2133
    • Integrated GPU Intel HD Graphics 530
    • Variants
      • i5-6300HQ – 2.30/3.20 GHz Turbo Boost
      • i5-6400T – 2.20 GHz/2.80 GHz Turbo Boost
      • i5-6400 – 2.70 GHz/3.30 GHz Turbo Boost
      • i5-6440hq
      • i5-6500T – 2.50 GHz/3.10 GHz Turbo Boost
      • i5-6500 – 3.20 GHz/3.60 GHz Turbo Boost
      • i5-6600T – 2.70 GHz/3.50 GHz Turbo Boost
      • i5-6600 – 3.30 GHz/3.90 GHz Turbo Boost
      • i5-6600K – 3.50 GHz/3.90 GHz Turbo Boost

Core i7 (6th generation)

edit
  • Skylake (Core i7 6th generation) – 14nm process technology
    • 4 physical cores/8 threads
    • 8 MB L3 cache
    • Introduced Q3'15
    • Socket 1151 LGA
    • 2-channel DDR3L-1333/1600, DDR4-1866/2133
    • Integrated GPU Intel HD Graphics 530
    • Variants
      • i7-6700T – 2.80 GHz/3.60 GHz Turbo Boost
      • i7-6700 – 3.40 GHz/4.00 GHz Turbo Boost
      • i7-6700K – 4.00 GHz/4.20 GHz Turbo Boost

Other Skylake processors

edit

Many Skylake-based processors are not yet listed in this section: mobile i3/i5/i7 processors (U, H, and M suffixes), embedded i3/i5/i7 processors (E suffix), certain i7-67nn/i7-68nn/i7-69nn.[37] Skylake-based "Core X-series" processors (certain i7-78nn and i9-79nn models) can be found under current models.

64-bit processors: Intel 64 (7th generation) – Kaby Lake microarchitecture

edit
Main article: Kaby Lake

64-bit processors: Intel 64 (8th and 9th generation) – Coffee Lake microarchitecture

edit
Main article: Coffee Lake

64-bit processors: Intel 64 – Cannon Lake microarchitecture

edit
Main article: Cannon Lake (CPU)

64-bit processors: Intel 64 (10th generation) – Ice Lake microarchitecture

edit
Main article: Ice Lake (microprocessor)

64-bit processors: Intel 64 (10th generation) – Comet Lake microarchitecture

edit
Main article: Comet Lake

64-bit processors: Intel 64 (11th generation) – Tiger Lake microarchitecture

edit
Main article: Tiger Lake

64-bit processors: Intel 64 (12th generation) – Alder Lake microarchitecture

edit
Main article: Alder Lake (microprocessor)

64-bit processors: Intel 64 (13th and 14th generation) – Raptor Lake microarchitecture

edit
Main article: Raptor Lake

Intel Tera-Scale

edit


Intel Xeon Phi

edit
Main article: Xeon Phi

Manycore processors, originating from the cancelled Larrabee processor.

  • 2010: Knights Ferry (32-core processor prototype on 45nm)
  • 2012: Knights Corner (Xeon Phi x100 series, with 57 to 61 cores on 22nm)
  • 2016: Knights Landing (Xeon Phi x200 series, with 64 to 72 cores on 14nm; introduced AVX-512)
  • 2017: Knights Mill (Xeon phi x205 series, with 64 to 72 cores on 14nm; added improved support for deep learning)

Intel Atom

edit
Main article: Intel Atom

Intel Quark

edit
Main article: Intel Quark

A product line of SoCs and microcontrollers, targeting much lower size and power consumption than Intel Atom.

  • 2013: Clanton (Quark X1000, SoC at 400 MHz, i586 instruction set with x87)
  • 2015: Silver Butte (Quark D1000, microcontroller at 32 MHz, runs reduced version of the IA-32 instruction set)
  • 2015: Mint Valley (Quark D2000, microcontroller at 32 MHz, i586 instruction set without x87)
  • 2015: Atlas Peak (Quark SE C1000, microcontroller at 32 MHz. i586 instruction set without x87)
  • 2017: Sue Creek (Quark S1000, non-x86[38])

C&T F8680

edit

The F8680 was an 80186-class SoC originally developed by Chips and Technologies, Inc. − after Intel acquired C&T in 1997, Intel continued shipments of this SoC until 2000.[39]

Intel 805xx product codes

edit

Intel discontinued the use of part numbers such as 80486 in the marketing of mainstream x86-architecture processors with the introduction of the Pentium brand in 1993. However, numerical codes, in the 805xx range, continued to be assigned to these processors for internal and part numbering uses. The following is a list of such product codes in numerical order:

Product code Marketing name(s) Codename(s)
80500 Pentium P5 (A-step)
80501 Pentium P5
80502 Pentium P54C, P54CS
80503 Pentium with MMX Technology P55C, Tillamook
80521 Pentium Pro P6
80522 Pentium II Klamath
80523 Pentium II, Celeron, Pentium II Xeon Deschutes, Covington, Drake
80524 Pentium II, Celeron Dixon, Mendocino
80525 Pentium III, Pentium III Xeon Katmai, Tanner
80526 Pentium III, Celeron, Pentium III Xeon Coppermine, Cascades
80528 Pentium 4, Xeon Willamette (Socket 423), Foster
80529 canceled Timna
80530 Pentium III, Celeron Tualatin
80531 Pentium 4, Celeron Willamette (Socket 478)
80532 Pentium 4, Celeron, Xeon Northwood, Prestonia, Gallatin
80533 Pentium III Coppermine (cD0-step)
80534 Pentium 4 SFF Northwood (small form factor)
80535 Pentium M, Celeron M 310–340 Banias
80536 Pentium M, Celeron M 350–390 Dothan
80537 Core 2 Duo T5xxx, T7xxx, Celeron M 5xx Merom
80538 Core Solo, Celeron M 4xx Yonah
80539 Core Duo, Pentium Dual-core T-series Yonah
80541 Itanium Merced
80542 Itanium 2 McKinley
80543 Itanium 2 Madison
80546 Pentium 4, Celeron D, Xeon Prescott (Socket 478), Nocona, Irwindale, Cranford, Potomac
80547 Pentium 4, Celeron D Prescott (LGA 775)
80548 canceled Tejas and Jayhawk
80549 Itanium 2 90xx Montecito
80550 Dual-core Xeon 71xx Tulsa
80551 Pentium D, Pentium EE, Dual-core Xeon Smithfield, Paxville DP
80552 Pentium 4, Celeron D Cedar Mill
80553 Pentium D, Pentium EE Presler
80554 Celeron 800/900/1000 ULV Shelton
80555 Dual-core Xeon 50xx Dempsey
80556 Dual-core Xeon 51xx Woodcrest
80557 Core 2 Duo E4xxx. E6xxx, Dual-core Xeon 30xx, Pentium Dual-core E2xxx Conroe
80560 Dual-core Xeon 70xx Paxville MP
80562 Core 2 Quad, Core 2 Extreme QX6xxx, Quad-core Xeon 32xx Kentsfield
80563 Quad-core Xeon 53xx Clovertown
80564 Xeon 7200 Tigerton-DC
80565 Xeon 7300 Tigerton
80566 Atom Z5xx Silverthorne
80567 Itanium 91xx Montvale
80569 Core 2 Quad Q9xxx, Core 2 Extreme QX9xxx, Xeon 33xx Yorkfield
80570 Core 2 Duo E8xxx, Xeon 31xx Wolfdale
80571 Core 2 Duo E7xxx, Pentium Dual-core E5xxx, Pentium Dual-core E2210 Wolfdale-3M
80573 Xeon 5200 Wolfdale-DP
80574 Core 2 Extreme QX9775, Xeon 5400 Harpertown
80576 Core 2 Duo P7xxx, T8xxx, P8xxx, T9xxx, P9xxx, SL9xxx, SP9xxx, Core 2 Extreme X9xxx Penryn
80577 Core 2 Duo P7xxx, P8xxx, SU9xxx, T6xxx, T8xxx Penryn-3M
80578 EP80578 Vermilion Range
80579 EP80579 Tolapai
80580 Core 2 Quad Q8xxx, Q9xxx, Xeon 33xx Yorkfield-6M
80581 Core 2 Quad Q9xxx Penryn-QC
80582 Xeon 74xx Dunnington
80583 Xeon 74xx Dunnington-QC
80584 Xeon X33x3 LV Yorkfield CL
80585 Core 2 Solo SU3xxx, Celeron 7xx, 9xx Penryn-L
80586 Atom 2xx, N2xx Diamondville
80587 Atom 3xx Diamondville DC
80588 Xeon L3014, E3113 Wolfdale-CL

Intel 806xx product codes

edit
Product code Marketing name(s) Codename(s)
80601 Core i7-9xx, Core i7-9xx Extreme Edition Bloomfield
80602 Xeon 55xx Gainestown
80603 Itanium 93xx Tukwila
80604 Xeon 65xx, Xeon 75xx Beckton
80605 Core i5-7xx, Core i7-8xx, Xeon 34xx Lynnfield
80606 canceled Havendale
80607 Core i7-7xx QM, Core i7-8xx QM, Core i7-9xx XM Clarksfield
80608 canceled Auburndale
80609 Atom Z6xx Lincroft
80610 Atom N400, D400, D500 Pineview
80611 canceled Larrabee
80612 Xeon C35xx, Xeon C55xx Jasper Forest
80613 Core i7-9xxX, Xeon 36xx Gulftown
80614 Xeon 56xx Westmere-EP
80615 Xeon E7-28xx, Xeon E7-48xx, Xeon E7-88xx Westmere-EX
80616 Pentium G6xxx, Core i3-5xx, Core i5-6xx Clarkdale
80617 Mobile Core i5-5xx, Core i7-6xxM/UM/LM Arrandale
80618 Atom E6x0 Tunnel Creek
80619 Core i7-3xxx Sandy Bridge-EP
80620 Xeon E5-24xx, Xeon E5-14xx, Pentium 14xx Sandy Bridge-EN
80621 Xeon E5-16xx, Xeon E5-26xx, Xeon E5-46xx Sandy Bridge-EP-8, Sandy Bridge-EP-4
80622 Sandy Bridge-EP-8
80623 Core i3/i5/i7-2xxx, Pentium Gxxx, Xeon E3-12xx Sandy Bridge-HE-4, Sandy Bridge-M-2
80627 Mobile Core i3/i5/i7-2xxxM, Pentium Bxxx, Celeron Bxxx Sandy Bridge-HE-4, Sandy Bridge-H-2, Sandy Bridge-M-2
80631 Itanium 95xx Poulson
80632 Atom E6x5C Stellarton
80633 Core i7-48xx, -49xx Ivy Bridge-E
80634 Xeon E5-24xx-v2, E5-14xx-v2, Pentium-14xx-v2 Ivy Bridge-EN
80635 Xeon E5-26xx-v2, E5-16xx-v2 Ivy Bridge-EP
80636 Xeon E7-v2 Ivy Bridge-EX
80637 Core i3/i5/i7-3xxx, Xeon E3-12xx-v2 Ivy Bridge
80638 Mobile Core i3/i5/i7-3xxxM Ivy Bridge
80640 Atom Z24xx Penwell
80641 Atom D2xxx, Atom N2xxx Cedarview
80642 Atom Z2xxx Penwell
80643 Xeon E5-14xx/24xx-v3 Haswell-EN
80644 Xeon E5-16xx/26xx-v3 Haswell-EP
80645 Xeon E7-48xx/88xx-v3 Haswell-EX
80646 Core i3/i5/i7 – 4xxx, Pentium G3xxx, Celeron G18xx, Xeon E3-12xx-v3 Haswell
80647 Mobile Core i5/i7 – 4xxxM Haswell-H, Haswell-M
80648 Core i7-58xx, -59xx Haswell-E
80649 Xeon Phi x100 Knight's Corner
80650 Atom Z27xx Cloverview
80651 Atom Z25xx Cloverview
80652 Atom Z34xx Merrifield
80653 Atom Z36xx, Atom Z37xx, Atom E38xx, Celeron N28xx, Celeron J1xxx, Celeron J28xx, Celeron J29xx, Pentium A10xx, Pentium J2xxx, Pentium N35xx Bay Trail-T, Bay Trail-I, Bay Trail-D, Bay Trail-M
80654 Atom C23xx Avoton
80655 Atom C2356 Rangeley
80658 Core i3/i5/i7 – 5xxx, Core M – 5Yxx Broadwell-Y, Broadwell-U, Broadwell-H
80660 Xeon E5-16xx-v4, Xeon E5-26xx-v4 Broadwell-EP
80661 Quark SoC X10xx Clanton
80662 Core i3/i5/i7-6xxx, Core m3/m5/m7-6Yxx, Pentium G4xxx, Xeon E3-12xx v5, Xeon E3-15xxM v5 Skylake
80663 Atom Z35xx Moorefield
80664 Atom x5-Z8xxx Cherry Trail
80665 Atom x5-E8000, Celeron N3xxx, Pentium N37xx, Celeron J3xxx, Pentium J37xx Braswell
80667 Xeon Phi x200 (standalone socketed processors) Knights Landing
80668 Celeron N/J33xx, Pentium N/J42xx, Atom x5/7-E39xx Apollo Lake
80671 Core i7-68xx, -69xx Broadwell-E
80673 Xeon Bronze/Silver/Gold/Platinum x1xx, Xeon D-21xx, Xeon W-21xx, 3175X, Core i7/i9-7xxx, 9xxx Skylake-X, Skylake-SP, Skylake-DE
80674 Xeon D-15xx Broadwell
80677 Core i3/i5/i7-7xxx Kaby Lake, Amber Lake
80679 Itanium 97xx Kittson
80680 Celeron N/J4xxx, Pentium N/J5xxx Gemini Lake
80682 Xeon D-16xx Hewitt Lake
80683 Xeon Phi 72x5 Knights Mill
80684 Core i3/i5/i7-8xxx, -8Yxx, 9xxx Coffee Lake, Whiskey Lake
80686 Xeon D-17xx, -18xx, -27xx, -28xx Ice Lake
80689 Core i3/i5/i7-10xxGx, Xeon Bronze/Silver/Gold/Platinum x3xx, Xeon W-33xx Ice Lake
80690 Core i3/i5/i7-11xxGx Tiger Lake
80691 Core i3/i5-LxxGx Lakefield
80692 Atom P5xxx Snow Ridge
80695 Xeon Bronze/Silver/Gold/Platinum x2xx, Xeon W-32xx Cascade Lake
80697 Celeron N45xx/51xx, Pentium Silver N60xx Jasper Lake

Intel 807xx product codes

edit
Product code Marketing name(s) Codename(s)
80701 Core i3/i5/i7/i9-10xxx Comet Lake
80703 Atom X6xxx, Celeron N/J62xx, Pentium N/J64xx Elkhart Lake
80706 Xeon Gold/Platinum x3xxH Cooper Lake
80708 Core i5/i7/i9-11xxx Rocket Lake
80711 Arc (Pro) Axxx Alchemist
80713 Xeon Bronze/Silver/Gold/Platinum/Max x4xx, Xeon w3/w5/w7/w9-x4xx Sapphire Rapids
80715 Atom X7xxx, Core i3/i5/i7/i9-12xxx, -13xxx, -14xxx, Core 3/5/7/9 1xx, 2xx, Processor 3xx, Nxxx Alder Lake, Raptor Lake, Amston Lake, Bartlett Lake, Twin Lake
80719 Atom C5xxx Parker Ridge
80720 Xeon 6xxxP Granite Rapids
80722 Xeon Silver/Gold/Platinum x5xx Emerald Rapids
80723 Core Ultra 5/7/9 1xx Meteor Lake
80726 Arc (Pro) Bxxx Battlemage
80729 Core Ultra 5/(X)7/(X)9 3xx Panther Lake
80765 Atom C3xxx Denverton
80767 Atom P6xxx Grand Ridge
80768 Core Ultra 5/7/9 2xx Arrow Lake
80771 Xeon 6xxxE Sierra Forest
80776 Core 3/5/7 3xx Wildcat Lake

See also

edit

Notes

edit
  1. ^ The 4004's original goal was to equal the clock rate of the IBM 1620 Model I (1 MHz); this was not quite met.

References

edit
  1. ^ Kennedy, Patrick (2026-06-01). "Intel Xeon 6+ Clearwater Forest is Out". ServeTheHome. Retrieved 2026-06-09.
  2. ^ "Intel Accidently Publishes Core Ultra 3 205 "Arrow Lake-S" CPU Specs". TechPowerUp. Retrieved 2025-09-01.
  3. ^ MSRP & Release date has very little info as intel has taken the CPU off of their website.
  4. ^ "Intel Core Ultra 9 288V specifications". CPU-World.
  5. ^ a b Intel (2023-12-14). "Intel Core Ultra Ushers in the Age of the AI PC". Newsroom. Retrieved 2026-06-05.
  6. ^ Robinson, Cliff (2023-06-15). "Intel Overhauls Core Branding with Meteor Lake". ServeTheHome. Retrieved 2026-06-05.
  7. ^ Bonshor, Gavin. "Intel Announces 14th Gen Core Series For Desktop: Core i9-14900K, Core i7-14700K and Core i5-14600K". www.anandtech.com. Archived from the original on October 17, 2023. Retrieved 2023-10-17.
  8. ^ "Intel Launches Intel Core 14th Gen Desktop Processors for Enthusiasts". Intel. Archived from the original on October 17, 2023. Retrieved 2023-10-17.
  9. ^ "Intel Releases 14th Gen Core HX "Raptor Lake Refresh" Mobile Processors". TechPowerUP. 8 January 2024.
  10. ^ Bonshor, Gavin (March 9, 2022). "The Intel W680 Chipset Overview: Alder Lake Workstations Get ECC Memory and Overclocking Support". AnandTech. Archived from the original on April 14, 2022. Retrieved April 14, 2022.
  11. ^ https://www.techpowerup.com/cpu-specs/core-i9-13980hx.c3016. {{cite web}}: Missing or empty |title= (help)
  12. ^ https://www.techpowerup.com/cpu-specs/core-i5-13600hx.c3030. {{cite web}}: Missing or empty |title= (help)
  13. ^ https://www.techpowerup.com/cpu-specs/core-i9-13900hk.c3047. {{cite web}}: Missing or empty |title= (help)
  14. ^ https://www.techpowerup.com/cpu-specs/core-i9-13905h.c3049. {{cite web}}: Missing or empty |title= (help)
  15. ^ https://www.techpowerup.com/cpu-specs/core-i7-1370p.c3055. {{cite web}}: Missing or empty |title= (help)
  16. ^ https://www.techpowerup.com/cpu-specs/core-i7-1365u.c3070. {{cite web}}: Missing or empty |title= (help)
  17. ^ "Intel Core i5 10300H - Detailed Specification and Benchmarks - Cpuscores". cpuscores.com. Retrieved 2026-01-16.
  18. ^ "Intel Core i7-8700T: Detailed Specifications and Benchmark Ratings - CpuTronic". CpuTronic.com. Retrieved 2024-12-24.
  19. ^ "Intel Core i5-8500T: Detailed Specifications and Benchmark Ratings - CpuTronic". CpuTronic.com. Retrieved 2024-12-24.
  20. ^ "Intel Core i3-8100T: Detailed Specifications and Benchmark Ratings - CpuTronic". CpuTronic.com. Retrieved 2024-12-24.
  21. ^ "Intel Unveils Full Intel Core X-series Processor Family Specs". Intel Newsroom. Archived from the original on 2017-08-07. Retrieved 2017-08-07.
  22. ^ "GIGABYTE – Motherboard – Socket 1151 – GA-Z170-HD3 DDR3 (rev. 1.0)". Gigabyte.com. Retrieved November 2, 2015.
  23. ^ "Z170-P D3 – Overview". Asus. Retrieved November 2, 2015.
  24. ^ "Z170 Pro4/D3". ASRock. Retrieved November 2, 2015.
  25. ^ Cutress, Ian (August 5, 2015). "The Intel 6th Gen Skylake Review: Core i7-6700K and i5-6600K Tested". AnandTech. Retrieved January 24, 2018.{{cite web}}: CS1 maint: deprecated archival service (link)
  26. ^ "Intel Processors". Archived from the original on 2012-04-24. Retrieved 2013-01-28.
  27. ^ a b c "Intel Microprocessor Quick Reference Guide – Product Family". Archived from the original on 2010-03-04. Retrieved 2010-01-08.
  28. ^ HAYES, JOHN.P (1978). Computer Architecture and Organization. McGraw-Hill International Book Company. p. 201. ISBN 0-07-027363-4.
  29. ^ a b c Intel IAPX 86,88 User's Manual, August 1981, Intel order number 210201-001
  30. ^ a b c d e Badri Ram (1 September 2001). Adv Microprocessors Interfacing. Tata McGraw-Hill Education. pp. 208–. ISBN 978-0-07-043448-6.
  31. ^ Rant, Jon; "Extending the Legacy of Leadership: The 80386 Arrives", Intel Corporation, Special 32-Bit Issue Solutions, November/December 1985, page 2
  32. ^ Intel Processor Spec Finder for Celeron M Archived November 3, 2009, at the Wayback Machine
  33. ^ Not listed as an official model by Intel but used by Apple in their Intel-based Mac Mini, released March 2006 Archived March 20, 2009, at the Wayback Machine
  34. ^ "Intel Pentium Processor G6950 (3M Cache, 2.80 GHz) with SPEC Code(s) SLBMS". Ark.intel.com. 2010-07-13. Archived from the original on 2011-03-09. Retrieved 2010-07-29.
  35. ^ a b "Intel Core X-series Processors in Intel's database on ark.intel.com". Archived from the original on 2017-12-08. Retrieved 2018-03-31.
  36. ^ "Broadwell CPUs on ark.intel.com". Archived from the original on 2018-03-31. Retrieved 2018-03-31.
  37. ^ "ark: Skylake". Archived from the original on 2018-03-31. Retrieved 2018-03-31.
  38. ^ CNX Software, Intel Quark S1000 “Sue Creek” Processor to Support On-Chip Speech Recognition, 19 Jun 2017.
  39. ^ Intel, Product Change Notification #847: F8680 Product Discontinuance, 23 July 1999. Archived from the original on 15 Aug 2000.
edit

📚 Artikel Terkait di Wikipedia

Intel 80386EX

aboard several orbiting satellites and microsatellites Used in NASA's FlightLinux project Used in USRobotics Courier I modem V.everything (Internal ISA

Embeddable Linux Kernel Subset

official release after a long hiatus in development. A development into FlightLinux, a real-time operating system for spacecraft, was planned, but the project

MIL-STD-1750A

and ANSI C compilers for the 1750A processor Ada and ANSI C compilers FlightLinux Project Target Architecture Technical Report References to use in spacecraft
